GENERAL ELECTRIC

TEB122015WL **Older Style** - 15Amp Circuit Breaker

TEB122015WL **Older Style** - 15Amp Circuit Breaker

Regular price $340.00 USD
Regular price Sale price $340.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122015WL **Older Style** - 15Amp Circuit Breaker

Replacing a circuit breaker in an older electrical system? Getting the right fit matters just as much as matching the electrical ratings. The TEB122015WL Older Style Black Face Circuit Breaker is a 15-amp, 2-pole2-pole molded-case industrial circuit breaker designed for compatible electrical equipment that requires this specific TEB configuration. Built with an E150 frame, it features a cable-in/cable-out (lug-lug) connection arrangement, with both line-side and load-side lugs included. That means you get the terminal configuration needed for applications designed around this breaker style. Its non-interchangeable thermal-magnetic trip unit protects against overloads and short circuits, while the 10 kA AIC rating at 120/240VAC defines its interrupting capacity at the specified voltage. The older-style black face is another detail to check when identifying a replacement for an existing installation.

Key Features and Benefits

  • 15 Amp, 2 Pole Configuration: Provides circuit protection for compatible electrical applications requiring a 15-amp, two-pole breaker.
  • E150 Frame Construction: Features a molded case design with dimensions suited to equipment that accepts this frame and breaker configuration.
  • Cable-In/Cable-Out (Lug-Lug): Designed with lug connections on both ends for applications requiring this particular wiring arrangement.
  • Line and Load-Side Lugs Included: Includes the specified terminal hardware for the breaker, helping ensure the correct connection arrangement.
  • Non-Interchangeable Trip Unit: Uses an integrated trip unit with a fixed configuration rather than a separately interchangeable trip assembly.

Technical Specifications

  • Part Number: TEB122015WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Series / Type: TEB
  • Frame Type: E150
  • Face Style: Older Style Black Face
  • Amperage Rating: 15 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity (AIC): 10,000 Amps (10k AIC) at 120/240VAC
  • Connection Type: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Lugs: Included
  • Load-Side Lugs: Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.
  • UPC: 00783164068511

Material Compliance and Certifications

The TEB122015WL circuit breaker features a molded case and a non-interchangeable thermal-magnetic trip unit. Its E150 frame and cable-in/cable-out connection arrangement are designed for electrical equipment that requires these specific characteristics.

Where It Works Best

Common applications include:

  • Legacy Electrical Systems: Replacement applications where an existing installation specifies the TEB122015WL or an approved equivalent with matching characteristics.
  • Industrial Electrical Distribution: Compatible industrial equipment requiring a 15 amp, two-pole molded case breaker with the specified voltage and interrupting ratings.
  • Commercial Electrical Equipment: Existing electrical assemblies designed to accommodate the E150 frame and cable-in/cable-out connection arrangement.
  • Facility Maintenance: Repair and replacement work involving older electrical distribution equipment with matching breaker requirements.
  • Lug-Lug Connection Applications: Installations that specifically require both line-side and load-side lug terminals.
