TEB122015WL - 15Amp Circuit Breaker

TEB122015WL - 15Amp Circuit Breaker

The TEB122015WL is a 2-pole, 15-amp molded-case circuit breaker designed for use in 120/240 VAC electrical distribution systems. Built on the E150 frame, it uses a non-interchangeable thermal magnetic trip unit to protect circuits from overloads and short circuits. This model features a cable-in/cable-out (lug-lug) design and includes both line-side and load-side lugs. If you're maintaining or repairing compatible electrical equipment, the TEB122015WL provides the correct form, fit, and function needed to keep existing systems operating as intended. Its compact design and published electrical ratings make it a practical choice for a wide range of commercial and industrial installations. Built to last, it's well-suited for facilities where dependable circuit protection is essential.

Key Features and Benefits

• 15 Amp Current Rating: 15 Amp current rating.
• Two-Pole Configuration: Two-pole configuration.
• E150 Frame Design: E150 frame design.
• Thermal Magnetic Trip Unit: Thermal magnetic trip unit with a non-interchangeable design.
• Cable-In/Cable-Out Connection: Cable-in/cable-out (lug-lug) connection.
• Line-Side and Load-Side Lugs Included: Includes both line-side and load-side lugs.
• 10kA Interrupting Capacity: Rated 10kA interrupting capacity at 120/240VAC.
• Form, Fit, and Functional Replacement: Designed for form, fit, and functional replacement in compatible equipment.
• Built to Last: Built to last in commercial and industrial environments.


Technical Specifications

• Part Number: TEB122015WL

• Type: TEB

• Frame: E150

• Poles: 2

• Amperage: 15A

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Connection Style: Cable-In/Cable-Out (Lug-Lug)

• Included: Line-Side and Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Application: The TEB122015WL is a molded case industrial circuit breaker intended for use in compatible electrical distribution equipment.
• Installation Guidance: Always verify that the breaker's frame, electrical ratings, and connection style match the requirements of your existing installation. Installation should be completed in accordance with applicable electrical codes and manufacturer recommendations.


Where It Works Best

• This breaker is commonly used in commercial and industrial electrical systems that require a 2-pole, 15-amp breaker for 120/240 VAC circuits. Typical applications include: Industrial control panels, Commercial distribution equipment, Manufacturing facilities, HVAC systems, Machinery and motor branch circuits, Maintenance and repair of compatible legacy electrical equipment.
