GENERAL ELECTRIC

TEB122015 **Older Style** - 15Amp Circuit Breaker

TEB122015 **Older Style** - 15Amp Circuit Breaker

Regular price $340.00 USD
Regular price Sale price $340.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122015 **Older Style** - 15Amp Circuit Breaker

Finding the right replacement circuit breaker for an older electrical system isn't always straightforward. You need the correct amperage, mounting style, and physical dimensions—not just a breaker that looks similar. The TEB122015 Older Style Black Face Circuit Breaker is a 15-amp, 2-pole molded case circuit breaker designed for compatible legacy electrical equipment. Built on an E150 frame, this TEB series breaker features a bolt-on mounting design and a non-interchangeable thermal magnetic trip unit that protects against overloads and short circuits. It has a 10 kA AIC rating at 120/240VAC and includes load-side lugs for conductor connections. The older-style black face is an important identifying feature, especially when matching a breaker already installed in an existing panel.

Key Features and Benefits

  • 15 Amp, 2-Pole Design: Provides overload and short-circuit protection for compatible electrical circuits.
  • Older Style Black Face: Helps identify the correct breaker style when replacing components in legacy electrical equipment.
  • E150 Frame: Molded case construction designed for compatible industrial electrical applications.
  • Bolt-On Mounting: Provides a secure mounting connection in electrical equipment designed for this breaker type.
  • Thermal Magnetic Protection: Uses thermal and magnetic trip mechanisms to respond to overloads and short circuits.

Technical Specifications

  • Part Number: TEB122015
  • Product Type: Molded Case Circuit Breaker
  • Series / Type: TEB
  • Frame Type: E150
  • Face Style: Older Style Black Face
  • Amperage Rating: 15 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity (AIC): 10,000 Amps (10k AIC) at 120/240VAC
  • Mounting Type: Bolt-On
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Load-Side Lugs: Included
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.
  • UPC: 00783164068504

Material Compliance and Certifications

The TEB122015 circuit breaker uses molded-case construction and a thermal-magnetic trip mechanism to provide circuit protection within its specified electrical ratings. Its E150 frame and bolt-on mounting configuration are intended for compatible electrical distribution equipment.

Where It Works Best

Common applications include:

  • Legacy Electrical Panels
  • Industrial Electrical Distribution
  • Commercial Electrical Systems
  • Electrical Equipment Maintenance
  • Existing Bolt-On Assemblies
