TEB122015 - 15Amp Circuit Breaker

TEB122015 - 15Amp Circuit Breaker

Finding the right replacement breaker starts with matching the original specifications. The TEB122015 is a 2-pole, 15-amp bolt-on molded case circuit breaker built on the E150 frame for use in your compatible commercial and industrial electrical distribution equipment. It features a non-interchangeable thermal-magnetic trip unit that helps you protect circuits from overloads and short circuits, along with a 10 kA interrupting rating at 120/240 VAC. Because this breaker uses a bolt-on mounting design, it installs securely in compatible panelboards and distribution equipment. Load-side lugs are included, helping streamline installation when replacing an existing unit. If you're maintaining older electrical equipment or replacing a breaker with matching ratings, the TEB122015 offers the form, fit, and function needed to keep the original system operating as intended. Built to last, it's a dependable choice for routine maintenance, repairs, and facility service work.

Key Features and Benefits

• Part Number: TEB122015
• 15 Amp Continuous Current Rating: 15 Amp continuous current rating.
• 2-Pole Configuration: 2-pole configuration.
• Bolt-On Mounting Design: Bolt-on mounting design.
• E150 Frame: E150 frame.
• Non-Interchangeable Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit.
• 10kA Interrupting Capacity: 10kA interrupting capacity at 120/240VAC.
• Includes Load-Side Lugs: Includes load-side lugs.
• Built to Last: Built to last for compatible electrical systems.
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for matching applications.

Technical Specifications

• Part Number: TEB122015
• Type: TEB
• Frame: E150
• Poles: 2
• Amperage: 15A
• Voltage: 120/240VAC
• Interrupting Rating: 10kA @ 120/240VAC
• Trip Unit: Non-Interchangeable Thermal Magnetic
• Mounting: Bolt-On
• Load-Side Lugs: Included
• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Construction: Molded case industrial circuit breaker construction.
• Thermal Magnetic Trip Mechanism: Thermal magnetic trip mechanism.
• Installation: Designed for installation in compatible equipment when applied according to applicable electrical codes and manufacturer specifications.
• Important: Always confirm amperage, voltage, interrupting rating, frame size, and mounting style before installation.

Where It Works Best

• The TEB122015 is commonly found in commercial buildings, industrial facilities, and other electrical distribution systems using compatible TEB E150 frame equipment. It's a practical replacement when the existing breaker has the same amperage, voltage, interrupting rating, and bolt-on configuration, allowing the original system design to remain unchanged.
