GENERAL ELECTRIC

SRPE30A25 - 25Amp GE Rating Plug

SRPE30A25 - 25Amp GE Rating Plug

Regular price $175.00 USD
Regular price Sale price $175.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

SRPE30A25 - 25Amp GE Rating Plug

When you're maintaining an existing electrical system, getting the details right matters. The ABB SRPE30A25 25 Amp Rating Plug is designed for SE150 frame circuit breakers that require an RMS1-rated plug with a 25-amp long-time trip setting. It's a small component with an important job: setting the breaker's long-time overload protection ampere rating.

Key Features and Benefits

  • 25 Amp Rating: Establishes a 25A long-time trip rating in a compatible circuit breaker and trip-unit combination.
  • SE150 Frame Compatibility: ABB identifies the SRPE30A25 for the SE150 circuit breaker frame.
  • RMS1 Rating Plug Configuration: Designed for applications that specifically call for an RMS1 25 Amp rating plug.
  • Interchangeable Design: Part of ABB's interchangeable rating plug system, allowing approved ampere ratings within the limits of a compatible breaker frame.
  • Exact Replacement Identification: Catalog number SRPE30A25 makes it easier to match the component specified for an existing electrical installation.

Technical Specifications

  • Manufacturer: ABB
  • Catalog Number: SRPE30A25
  • Manufacturer Description: RMS1 25 AMP RATING PLUG
  • Product Type: Interchangeable circuit breaker rating plug
  • Product Category: Accessories
  • Rating Plug Designation: RMS1
  • Frame Type: SE150
  • Rated Amperage: 25A
  • Primary Function: Establishes the long-time trip rating of a compatible circuit breaker
  • Rating Plug Configuration: Interchangeable
  • Intended Application: Manufacturer-approved SE150 circuit breaker and trip-system combinations
  • Replacement Function: Form, fit, and functional replacement where SRPE30A25 is specified
  • UPC: 783164213829
  • GO Schedule: 135S
  • GSA Compliance: No
  • UL File Number: E11592
  • CSA File Number: LR40350

Material Compliance and Certifications

The ABB SRPE30A25 rating plug is part of the manufacturer's interchangeable rating plug family, which is used to establish or change the long-time trip point of compatible circuit breakers. ABB provides the following classification and compliance information for this catalog number:

  • UL Listing Reference: ABB describes its interchangeable rating plug system as UL listed and identifies UL File E11592. Confirm the applicable listing and approved breaker configuration before installation.
  • CSA Certification Reference: The manufacturer publishes CSA File LR40350. Verify the relevant certification scope for the complete equipment configuration.
  • GSA and Material Compliance: GSA Compliance: No. The supplied manufacturer specifications do not include separate RoHS, REACH, or material composition declarations.

Where It Works Best

  • SE150 Circuit Breaker Maintenance
  • 25A Rating Plug Replacement
  • RMS1 Rating Plug Replacement
  • Legacy Spectra Circuit Breaker Servicing
  • Commercial Electrical Distribution Systems
  • Industrial Electrical Distribution Systems
  • Existing Circuit Breaker Configuration Matching
  • Electrical Panel Maintenance
  • Facility Electrical Maintenance Programs
  • Long-Time Trip Rating Restoration
  • Preventive Electrical Maintenance
  • Manufacturer-Specified Component Replacement
