GENERAL ELECTRIC

SRPE100A80 - 80Amp GE Rating Plug

SRPE100A80 - 80Amp GE Rating Plug

Regular price $175.00 USD
Regular price Sale price $175.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

SRPE100A80 - 80Amp GE Rating Plug

The GE SRPE100A80 80 Amp Rating Plug is designed for compatible SE150 frame Spectra circuit breakers and provides the specified 80A rating needed to set the breaker's long-time trip point. When you're maintaining an existing electrical distribution system, the right replacement part makes all the difference in keeping equipment configured as intended. The SRPE100A80 is an interchangeable RMS-rated plug that the manufacturer identifies as a standard SE150 100/80 configuration.

Key Features and Benefits

  • 80 Amp Rating: Establishes an 80A long-time trip rating in a compatible circuit breaker.
  • SE150 Frame Compatibility: Specified for the SE150 breaker frame.
  • Standard 100/80 Configuration: The manufacturer identifies this as an SE150 standard 100/80 rating plug.
  • Interchangeable RMS Design: Supports rating plug replacement within the permissible current ratings of the applicable breaker frame.
  • Long-Time Trip Function: Establishes the ampere rating used by the breaker's long-time overload protection function.

Technical Specifications

  • Manufacturer: GE
  • Catalog Number: SRPE100A80
  • Product Type: Interchangeable RMS rating plug
  • Manufacturer Description: SE150 Rating Plug (STD) 100/80
  • Accessory Category: Circuit breaker accessory
  • Frame Type: SE150
  • Ampere Rating: 80A
  • Manufacturer Configuration: Standard (STD) 100/80
  • Rating Function: Establishes the circuit breaker's long-time trip point
  • Rating Plug Design: Interchangeable
  • Applicable Breaker Family: Spectra, subject to SE150 frame and trip-system compatibility
  • Intended Use: Establishing or replacing the 80A rating in a compatible breaker
  • UPC: 783164213102
  • UL File Number: E11592
  • CSA File Number: LR40350
  • GSA Compliance: Yes
  • GO Schedule: 135S

Material Compliance and Certifications

Manufacturer documentation identifies the SRPE100A80 as part of an interchangeable circuit breaker rating plug system with the following compliance information.

  • UL Listed: The manufacturer describes its interchangeable rating plugs as UL listed and identifies UL File E11592.
  • CSA Certification Reference: The manufacturer's classification data lists CSA File LR40350. Verify the applicable certification scope for the exact breaker and rating plug combination.
  • GSA Compliance: The manufacturer lists it as GSA compliant.

Where It Works Best

The SRPE100A80 is intended for maintenance and replacement applications where an approved SE150 frame circuit breaker requires an 80A RMS rating plug.

  • SE150 Circuit Breaker Maintenance
  • 80A Rating Plug Replacement
  • Commercial Electrical Distribution Systems
  • Industrial Electrical Installations
  • Compatible Legacy Spectra Breaker Systems
  • Electrical Panel Maintenance
  • Facility Electrical Maintenance
  • Long-Time Trip Rating Restoration
  • Existing Breaker Servicing
  • Electrical Distribution Equipment Repairs
  • Preventive Maintenance Programs
  • Manufacturer-Approved Replacement Applications
