SRPE100A70 - 70Amp GE Rating Plug
SRPE100A70 - 70Amp GE Rating Plug
Couldn't load pickup availability
SRPE100A70 - 70Amp GE Rating Plug
The GE SRPE100A70 70 Amp RMS Rating Plug is designed for compatible SE150 frame Spectra circuit breakers, providing a straightforward way to set the breaker's 70A long-time trip rating. When you're maintaining an existing electrical distribution system, finding the correct replacement component matters. Built for lasting service in its intended application, this rating plug offers the form, fit, and function needed for compatible legacy installations. Whether you're replacing an existing 70A plug or restoring a breaker to its specified configuration, the SRPE100A70 provides a manufacturer-defined solution for maintaining the correct long-time trip setting.
Key Features and Benefits
- 70 Amp RMS Rating: Establishes a 70A long-time trip rating in a compatible circuit breaker.
- SE150 Frame Compatibility: Designed for use with the specified SE150 breaker frame.
- Interchangeable Rating Plug Design: Allows you to set the breaker rating with an appropriate plug within the frame's permitted current range.
- Long-Time Trip Setting: Determines the breaker's long-time trip point for overload protection.
- UL-Listed Rating Plug Family: Part of the manufacturer's interchangeable rating plug system described as UL-listed.
- Service-Friendly Component: Supports maintenance and replacement work without treating the rating plug as a complete breaker.
Technical Specifications
-
Manufacturer: GE
-
Catalog Number: SRPE100A70
-
Product Type: Interchangeable RMS rating plug
-
Product Description: SE150 70A RMS Rating Plug
-
Accessory Category: Circuit breaker accessory
-
Frame Type: SE150
-
Ampere Rating: 70A
-
Rating Function: Establishes the circuit breaker's long-time trip point
-
Rating Plug Type: Interchangeable
-
Compatible Breaker Family: Spectra, subject to the specified SE150 frame and trip-system requirements
-
Application: Establishing or replacing the 70A rating in a compatible breaker
-
UPC: 783164213096
-
UL File Number: E11592
-
CSA File Number: LR40350
-
GSA Compliance: No
Material Compliance and Certifications
The SRPE100A70 uses a manufacturer-documented plug system with the following compliance references.
- UL Listed: The manufacturer identifies its interchangeable rating plugs as UL listed and provides UL File E11592.
- CSA Certification Reference: Manufacturer documentation provides CSA File LR40350; confirm the applicable certification scope for the exact product and breaker combination.
- GSA Compliance: The manufacturer lists it as not GSA compliant.
Where It Works Best
The SRPE100A70 is intended for electrical maintenance and replacement applications where a compatible SE150 frame breaker requires a 70A RMS rating plug.
- SE150 Circuit Breaker Maintenance
- 70A Rating Plug Replacement
- Commercial Electrical Distribution Systems
- Industrial Electrical Installations
- Legacy Spectra Breaker Systems
- Electrical Panel Servicing
- Facility Maintenance Work
- Long-Time Trip Setting Maintenance
- Electrical Distribution Repairs
- Existing Equipment Restoration
- Preventive Maintenance Programs
- Manufacturer-Approved Breaker Applications
