SRPE100A100 - 100Amp GE Rating Plug
SRPE100A100 - 100Amp GE Rating Plug
Couldn't load pickup availability
SRPE100A100 - 100Amp GE Rating Plug
The right replacement part can make all the difference when you're keeping an existing electrical system in service. The ABB SRPE100A100 Rating Plug is a 100 Amp standard rating plug made for compatible SE150 frame circuit breakers. It has one important job: establishing the breaker's long-time trip current setting. That setting helps determine how the breaker responds to sustained overcurrent conditions. For electricians and maintenance teams working with existing equipment, matching the original rating plug is often the simplest way to preserve the intended breaker configuration.
Key Features and Benefits
- 100 Amp Rating: Establishes a 100A long-time trip current setting in compatible equipment.
- Designed for SE150 Frames: Intended for use with the specified SE150 circuit breaker frame.
- Standard 100/100 Configuration: Matches the manufacturer's designated standard rating plug specification.
- Interchangeable Rating Plug Design: Supports approved rating plug configurations within compatible breaker frames.
- Long-Time Trip Control: Sets the current rating used by the breaker's long-time protection function.
- Conductor Rating Considerations: Allows the breaker's established ampere rating to be checked against connected cable and bus bar ampacity.
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: SRPE100A100
-
Product Description: SE150 Rating Plug (Standard) 100/100
-
Product Type: Circuit Breaker Rating Plug
-
Product Category: Electrical Accessory
-
Rating Plug Series: SRPE100A
-
Frame Type: SE150
-
Amperage: 100 A
-
Rating Plug Configuration: Standard 100/100
-
Function: Establishes the circuit breaker's long-time trip current rating
-
Design: Interchangeable rating plug
-
UPC: 783164213126
-
UL File Number: E11592
-
CSA File Number: LR40350
-
GSA Compliance: No
Material Compliance and Certifications
The manufacturer provides the following listing and compliance information for the SRPE100A100 rating plug:
- UL Listed: The rating plug family is described as UL Listed, with UL File E11592 provided for reference. Verify coverage for the exact catalog number.
- CSA Certification: CSA File LR40350 is listed in the manufacturer's classification details. Confirm the applicable product certification before installation.
- Material and Regulatory Compliance: GSA Compliance: No is specified. Material composition and other environmental compliance details are not provided in the available specifications.
Where It Works Best
The SRPE100A100 is a practical replacement choice when an existing electrical installation calls for a 100A standard-rated plug in a compatible SE150 frame breaker.
- SE150 Circuit Breaker Maintenance
- Direct Rating Plug Replacement
- Commercial Electrical Systems
- Industrial Electrical Installations
- Legacy Electrical Equipment
- Electrical Panel Servicing
- Facility Maintenance Work
- Long-Time Trip Setting Maintenance
- Electrical Distribution Repairs
- Equipment Restoration Projects
- Preventive Maintenance Programs
- Manufacturer-Approved Applications
