SMD69700ANGT - 700Amp Circuit Breaker

SMD69700ANGT - 700Amp Circuit Breaker

The Siemens SMD69700ANGT is a high-capacity low voltage SENTRON molded case circuit breaker, meticulously engineered to deliver exceptional performance and reliability in demanding electrical applications. Featuring an advanced electronic trip unit (ETU), this circuit breaker ensures precise and dependable protection. With a substantial 700A current rating and a 3-pole configuration, the SMD69700ANGT meets the stringent requirements of UL 489 and IEC 60947-2 standards, providing robust protection and operational efficiency. Its compact design and versatile wire range make it a flexible solution for a variety of electrical distribution systems, ensuring continuous and reliable operation.

Key Features and Benefits:

• Advanced Electronic Trip Unit (ETU): Provides accurate and reliable tripping characteristics, enhancing the protection and efficiency of your electrical systems.
• High Interrupting Capacity: Rated at 25kAIC at 600V and 50kAIC at 480V, this breaker effectively handles high fault currents, ensuring the safety and longevity of your equipment.
• Durable MD Frame: Standard 40å¡C breaker MD frame ensures long-lasting durability and reliable performance in diverse environments.
• Versatile Connectivity: Equipped with line and load side lugs (TA3K500), compatible with a wide wire range of 1/0AWG - 500KCM (CU/AL).
• Compact Design: Dimensions of 9 x 16 x 6 inches allow for easy integration into various electrical panels and enclosures.
• Sensitrip Functions: Provides enhanced monitoring and control capabilities, ensuring optimal performance and safety in electrical circuits.

Technical Specifications:

• Manufacturer: Siemens
• Model: SMD69700ANGT
• Type: Low Voltage SENTRON Molded Case Circuit Breaker
• Current Rating: 700A
• Poles: 3
• Interrupting Capacity: 25kAIC at 600V, 50kAIC at 480V
• Frame: MD Frame, Standard 40å¡C
• Wire Range: 1/0AWG - 500KCM (CU/AL)
• Dimensions: 9 x 16 x 6 inches
• Weight: 61.5 lbs

Material Compliance and Certifications:

• Standards Compliance: Meets UL 489 and IEC 60947-2 standards for circuit breakers.
• RoHS Compliance: Conforms to the Restriction of Hazardous Substances (RoHS) directive since March 30, 2009.
• Country of Origin: Mexico

Suitability:

• The Siemens SMD69700ANGT is ideal for a wide range of applications, including industrial facilities, commercial buildings, and other settings requiring high-reliability electrical protection. Its high interrupting capacity and advanced electronic trip unit make it particularly suitable for systems exposed to high fault currents, ensuring continuous and dependable operation.
