SGPA26AT0600 - 600Amp Max. *Frame Only*

SGPA26AT0600 - 600Amp Max. *Frame Only*

When keeping an existing electrical distribution system operating as intended, finding the right replacement breaker frame matters. The SGPA26AT0600 is a 2-pole, 600 amp SGPA series molded case circuit breaker frame built for use in the SG600 product line. This is a frame only configuration, designed for applications that require a compatible electronic trip assembly to complete the breaker.

With a current-limiting design and interrupting ratings of 100kA at 480VAC and 200kA at 240VAC, the SGPA26AT0600 is well suited for industrial and commercial power distribution systems where high available fault current is present. Its durable construction is built to last, making it an excellent choice when maintaining existing equipment without changing the original system design. Whether you're replacing a damaged breaker frame or restoring an existing installation, this model provides the form, fit, and functional compatibility needed for many SG600 applications.

Key Features and Benefits

• Frame Only: Designed for applications requiring a compatible SG600 series breaker frame. Trip unit is not included.
• 600 Amp Rating: Supports high-current industrial and commercial electrical systems.
• 2-Pole Configuration: Compatible with two-pole power distribution applications.
• Current-Limiting Design: Helps reduce the amount of fault current that reaches downstream equipment during short-circuit events.
• Electronic Trip Compatible: Designed for use with the appropriate compatible electronic trip unit.
• High Interrupting Capacity: Rated for 100kA at 480VAC and 200kA at 240VAC.
• Built to Last: Manufactured for long-term service in demanding electrical environments.
• Form, Fit, and Functional Replacement: Ideal for maintaining compatibility with existing SG600 installations.


Technical Specifications

• Part Number: SGPA26AT0600

• Type: SGPA

• Product Line: SG600

• Product Configuration: Frame Only

• Trip Type: Electronic Trip Compatible

• Poles: 2

• Amperage: 600A

• Interrupting Rating: 100kA @ 480VAC; 200kA @ 240VAC

• Current Limiting: Yes

• Dimensions:
  • Height: 10.09 in.
  • Width: 5.50 in.
  • Depth: 3.81 in.

Material Compliance and Certifications

• Application: Designed for use in compatible SG600 molded case circuit breaker assemblies.
• Current-Limiting Design: Current-limiting design suitable for applications requiring high interrupting capacity.
• Industry Standards: Manufactured to meet applicable industry standards for its product family.
• Compatibility: Always verify compatibility with the existing breaker frame, trip unit, and system requirements before installation.


Where It Works Best

• The SGPA26AT0600 is commonly found in industrial facilities, manufacturing plants, commercial buildings, utilities, and other heavy-duty electrical distribution systems that rely on compatible SG600 series breaker assemblies. It's a practical solution for maintenance, repair, and replacement projects where preserving the original equipment configuration is important. Because this unit is supplied as a frame only, it's intended for installations using the appropriate compatible electronic trip components while maintaining the existing system's design and ratings.
