SGHA26AT0400 - 400Amp Max. *Frame Only*

SGHA26AT0400 - 400Amp Max. *Frame Only*

When you're maintaining or repairing an existing SG600 line electrical distribution system, finding the right replacement components matters. The SGHA26AT0400 is a 2-pole, 400-amp industrial molded case circuit breaker frame designed for applications that use a compatible electronic trip system. Because this is a frame only, it's intended for installations where the appropriate electronic trip components are already being used or will be installed separately. Designed as a form, fit, and functional replacement, the SGHA26AT0400 helps keep existing electrical systems operating without requiring unnecessary modifications. Its current-limiting design and interrupting ratings of 35kA at 480VAC and 65kA at 240VAC make it suitable for a wide range of industrial and commercial power distribution applications. Built for long-term service, this breaker frame is commonly used in facilities where dependable circuit protection and equipment compatibility are essential. Whether you're replacing a damaged breaker frame during scheduled maintenance or sourcing a compatible component for an existing installation, the SGHA26AT0400 provides the ratings and configuration needed for many legacy electrical systems.

Key Features and Benefits

• SGHA Series Circuit Breaker Frame: SGHA series industrial molded case circuit breaker frame only.
• SG600 Product Line: Designed for use within the SG600 product line.
• Two-Pole Configuration: 2-pole configuration.
• 400 Amp Frame Rating: 400 Amp frame rating.
• Current-Limiting Design: Current-limiting design.
• Electronic Trip Compatibility: Compatible with electronic trip applications.
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for compatible systems.
• Built to Last: Built to last in demanding commercial and industrial environments.
• Compact Dimensions: Compact dimensions help simplify installation in compatible equipment.


Technical Specifications

• Part Number: SGHA26AT0400

• Type: SGHA

• Product Line: SG600

• Product Category: Industrial Molded Case Circuit Breaker Frame Only

• Poles: 2

• Amperage: 400A

• Interrupting Rating: 35kA @ 480VAC; 65kA @ 240VAC

• Trip Type: Electronic Trip (Compatible Application)

• Current Limiting: Yes

• Dimensions:
  • Height: 10.09 in.
  • Width: 5.50 in.
  • Depth: 3.81 in.
• Additional Notes: Frame Only


Material Compliance and Certifications

• Industrial Electrical Systems: Manufactured for use in compatible industrial electrical distribution systems.
• Installation Requirements: Intended for installation in accordance with applicable manufacturer specifications.
• Compatibility Verification: Verify compatibility with the required electronic trip unit and associated equipment before installation.
• Code Compliance: Install and maintain in accordance with applicable local, state, and national electrical codes.


Where It Works Best

• The SGHA26AT0400 is commonly used in commercial and industrial electrical distribution systems that utilize compatible SG600 series molded case circuit breakers. Typical applications include switchboards, panelboards, industrial control equipment, manufacturing facilities, processing plants, commercial buildings, and other power distribution systems requiring a 400-amp, 2-pole breaker frame with current-limiting capability.
