SFPA24AT0250 - 250Amp Max. *Frame Only*

SFPA24AT0250 - 250Amp Max. *Frame Only*

The SFPA24AT0250 is a 2-pole, 250 Amp molded case circuit breaker frame from the SF250 Line. This listing is for the frame only and is intended for applications that use a compatible electronic trip system. If you're replacing an existing breaker frame, matching the original part number and ratings is one of the easiest ways to help ensure compatibility with your equipment. This breaker frame features a current-limiting design and is rated for interrupting capacities of 25kA at 600VAC, 65kA at 480VAC, and 100kA at 240VAC. Measuring 10.12 inches high, 4.12 inches wide, and 3.38 inches deep, it is designed to fit equipment built around the SFPA platform. Because this is a frame-only assembly, an electronic trip unit is required for a complete installation. Built to last, the SFPA24AT0250 is commonly used during maintenance, equipment repairs, and replacement projects where maintaining the original configuration of an existing electrical distribution system is important.

Key Features and Benefits

• Part Number: SFPA24AT0250
• SFPA Series Molded Case Circuit Breaker Frame: SFPA Series molded case circuit breaker frame.
• Frame Only: This listing is for the frame only and is intended for applications that use a compatible electronic trip system.
• 250 Amp Rating: Rated for 250 Amps.
• 2 Poles: Configured with 2 poles.
• Current-Limiting Construction: Features a current-limiting design.
• Designed for Compatible Electronic Trip Units: Requires a compatible electronic trip unit for complete installation.
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for compatible equipment.
• Built to Last: Commonly used during maintenance, equipment repairs, and replacement projects where maintaining the original configuration of an existing electrical distribution system is important.


Technical Specifications

• Part Number: SFPA24AT0250

• Type: SFPA

• Frame Line: SF250

• Product: Molded Case Circuit Breaker Frame

• Configuration: Frame Only

• Poles: 2

• Current Rating: 250 Amps

• Trip Type: Electronic Trip Compatible

• Interrupting Ratings:
  • 25kA @ 600VAC
  • 65kA @ 480VAC
  • 100kA @ 240VAC
• Dimensions:
  • Height: 10.12 in.
  • Width: 4.12 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Application Requirements: This breaker frame is manufactured for use in compatible commercial and industrial electrical distribution systems. Verify part number, frame type, trip unit compatibility, voltage, interrupting rating, and application requirements before installation.
• Installation: Installation should be completed by qualified personnel in accordance with applicable electrical codes and manufacturer recommendations.


Where It Works Best

• The SFPA24AT0250 is commonly installed in manufacturing facilities, commercial buildings, processing plants, institutional facilities, and other locations that rely on compatible SFPA Series electrical distribution equipment. It is intended for maintenance and replacement projects where preserving the original equipment configuration is required.
