SEPA24AT0150 - 150Amp Max. *Frame Only*

SEPA24AT0150 - 150Amp Max. *Frame Only*

If you're replacing a breaker in an existing SE150 Line installation, the SEPA24AT0150 is designed to match the original equipment's form, fit, and function. This 2-pole, 150-amp molded case circuit breaker frame features an electronic trip configuration and is intended for use with the appropriate compatible trip unit. Because this is a frame-only unit, it does not include the trip assembly. With interrupting ratings of 100kA at 480VAC and 200kA at 240VAC, it is suited for commercial and industrial electrical systems where those ratings are required. Built to last, the SEPA24AT0150 is often used in maintenance and repair projects to keep existing equipment in service without altering the original system design.

Key Features and Benefits

• SE150 Line: SE150 Line molded case circuit breaker frame.
• Part Number: SEPA24AT0150.
• Frame Only: Frame only (trip unit not included).
• 2-Pole Configuration: 2-pole configuration.
• 150 Amp Rating: 150 Amp rating.
• Electronic Trip Design: Electronic trip design.
• Interrupting Ratings:
  • 100kA interrupting rating at 480VAC
  • 200kA interrupting rating at 240VAC
• Compatible Equipment: Designed for use in compatible SE150 Line equipment.
• Built for Long Service Life: Built for long service life.


Technical Specifications

• Part Number: SEPA24AT0150

• Type: SEPA

• Series: SE150 Line

• Configuration: Frame Only

• Poles: 2

• Amperage: 150A

• Trip Type: Electronic

• A.I.C. Rating:
  • 100kA @ 480VAC
  • 200kA @ 240VAC
• Dimensions:
  • Height: 6.5 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Commercial and Industrial Applications: Manufactured for commercial and industrial electrical distribution applications.
• Electrical Codes: Designed for installation in compatible equipment that meets applicable electrical codes.
• Compatibility: Compatibility with the required trip unit should be verified before installation.
• Installation: Installation should be performed by qualified electrical personnel.


Where It Works Best

• The SEPA24AT0150 is commonly found in commercial buildings, manufacturing facilities, processing plants, and other industrial power distribution systems using compatible SE150 Line equipment. It works well for maintenance projects where the goal is to replace a damaged breaker frame with the correct compatible component.
