SEPA24AT0100 - 100Amp Max. *Frame Only*

SEPA24AT0100 - 100Amp Max. *Frame Only*

Keeping an existing electrical system running often comes down to finding the right replacement component. The SEPA24AT0100 is a 2-pole, 100-amp molded-case circuit breaker frame from the SE150 line, designed for use in compatible commercial and industrial power distribution equipment. This model features an electronic trip design and is supplied as a frame-only unit, making it a practical choice for maintaining equipment that already uses this breaker style.

Its interrupting capacity is rated at 100 kA at 480 VAC and 200 kA at 240 VAC, making it suitable for applications where a higher available fault current is present. Whether you're replacing a worn breaker frame during scheduled maintenance or repairing existing equipment, matching the original ratings and configuration helps keep the installation consistent with its intended design.

Instead of changing the system or modifying connected equipment, many maintenance teams need a breaker that is correctly suited to the application. The SEPA24AT0100 is built for that purpose. It offers the electrical ratings and physical configuration expected for compatible SE150 installations and is built to last in demanding commercial and industrial environments.

Key Features and Benefits

• 100 Amp Current Rating: 100 Amp current rating.
• 2-Pole Configuration: 2-pole configuration.
• Electronic Trip Design: Electronic trip design.
• SE150 Product Line: Part of the SE150 molded case circuit breaker family.
• Frame Only Configuration: Frame only configuration.
• Interrupting Rating: Interrupting rating of 100kA at 480VAC.
• High Interrupting Rating: Interrupting rating of 200kA at 240VAC.
• Form, Fit, and Functional Replacement: Designed for form, fit, and functional replacement in compatible equipment.
• Built to Last: Built to last in commercial and industrial applications.

Technical Specifications

• Part Number: SEPA24AT0100
• Type: SEPA
• Product Line: SE150
• Configuration: Frame Only
• Trip Unit: Electronic
• Poles: 2
• Current Rating: 100 Amps
• Interrupting Rating: 100kA @ 480VAC; 200kA @ 240VAC
• Dimensions:
  • Height: 6.5 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Manufacturing: Manufactured for use in compatible commercial and industrial electrical systems.
• Installation: Electrical ratings should always be verified before installation. Install in accordance with applicable local, state, and national electrical codes.

Where It Works Best

• The SEPA24AT0100 is commonly used in industrial facilities, manufacturing plants, commercial buildings, switchboards, panelboards, and other power distribution equipment that use compatible SE150 molded-case circuit breakers. Because this unit is supplied as a frame only, it is best suited for maintenance and repair projects where preserving the original equipment configuration is the priority.
