SEPA24AT0030 - 30Amp Max. *Frame Only*

SEPA24AT0030 - 30Amp Max. *Frame Only*

When keeping an existing electrical distribution system operating properly, using the correct replacement component matters. The SEPA24AT0030 is a 2-pole, 30 amp industrial molded case circuit breaker frame from the SE150 line, designed for applications that require a Type SEPA breaker with an electronic trip configuration. This frame-only unit is intended as a form, fit, and functional replacement for compatible equipment, making it a practical solution for maintenance, repairs, and system servicing. With interrupting ratings of 100kA at 480VAC and 200kA at 240VAC, it is built to handle demanding commercial and industrial environments while helping maintain compatibility with your existing installation. Whether you're replacing a worn breaker frame during scheduled maintenance or restoring equipment to service, the SEPA24AT0030 delivers the dimensions, ratings, and configuration needed for the job. Like the rest of the SE150 family, it is built to last and intended for long-term use in compatible electrical systems.

Key Features and Benefits

• Part Number: SEPA24AT0030
• Product Line: SE150 Series industrial molded case circuit breaker
• Configuration: Frame only configuration
• Trip Type: Electronic trip design
• Construction: 2-pole construction
• Current Rating: 30 Amp current rating
• Interrupting Capacity:
  • 100kA @ 480VAC
  • 200kA @ 240VAC
• Replacement Application: Designed as a form, fit, and functional replacement for compatible SE150 applications.
• Durability: Built to last for demanding commercial and industrial environments.

Technical Specifications

• Part Number: SEPA24AT0030
• Type: SEPA
• Product Line: SE150
• Configuration: Frame Only
• Trip Type: Electronic Trip
• Poles: 2
• Amperage: 30A
• Interrupting Rating: 100kA @ 480VAC; 200kA @ 240VAC
• Dimensions:
  • Height: 6.5 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Industrial Applications: Manufactured for industrial electrical distribution applications.
• Electrical Ratings: Designed to meet the published electrical ratings of the SE150 product line.
• Installation Notice: Always verify compatibility with your equipment and applicable electrical codes before installation.

Where It Works Best

• The SEPA24AT0030 is commonly used in commercial and industrial facilities where maintaining existing electrical infrastructure is a priority. It is well suited for compatible switchboards, panelboards, motor control equipment, and power distribution systems that require a 30A, 2-pole Type SEPA breaker frame with an electronic trip. Because this is a frame-only component, it is intended for applications where the correct replacement frame is needed to match the original equipment's form, fit, and function.
