SELA24AT0150 - 150Amp Max. *Frame Only*

SELA24AT0150 - 150Amp Max. *Frame Only*

Unlock unparalleled safety and reliability with the Spectra RMS SELA24AT0150 Circuit Breaker, a robust solution tailored for advanced electrical systems. Engineered for precision and durability, this two-pole circuit breaker is designed to handle a load capacity of 150A and system voltages of 240/480V, ensuring robust protection for both residential and commercial setups. With an exceptional interrupting rating of 100 KAIC at 240V, it provides optimal safety by preventing electrical faults and potential fires. This is a frame-only model and requires a compatible trip unit to function as a complete circuit breaker.

Key Features and Benefits:

• Adjustable Trip Settings: Incorporate field-installable, front-mounted rating plugs to easily adjust the breakers ampere rating, enhancing flexibility and customization.
• Comprehensive Protection: Features LSI (Long-Time, Short-Time, Instantaneous) trip functions, allowing for precise control and dependable protection against overloads and short circuits.
• Digital, Solid State RMS Sensing: Utilizes advanced digital sampling to accurately determine the RMS value of sinusoidal and non-sinusoidal currents, which enhances the accuracy and responsiveness of the trip system.
• Reverse Feed Capable: Versatile installation options with safe and efficient reverse feed capability.

Technical Specifications:

• Poles: 2
• Amperage: Available in 110A, 125A, and 150A ratings.
• System Voltage: Supports multiple voltages including 120 Vac, 120/240 Vac, 240 Vac, 277 Vac, and 480 Vac.
• Frame Type: SE150
• Interrupting Rating: Provides 100 KAIC at 240 Vac and 65 KAIC at 480 Vac.

Material Compliance and Certifications:

• Ensure peace of mind with rigorous compliance to UL and CSA standards, verifying the breaker's safety and quality.

Suitability:

• Ideal for a broad range of applications including commercial buildings, industrial plants, and large residential complexes. Its adjustable settings and high interrupting capacity make it suitable for systems requiring precise protective measures.

Equip your electrical installations with the SELA24AT0150, and ensure maximum protection and operational efficiency.
