GENERAL ELECTRIC
SEDA24AT0060 - 60Amp Max. *Frame Only*
SEDA24AT0060 - 60Amp Max. *Frame Only*
Couldn't load pickup availability
SEDA24AT0060 - 60Amp Max. *Frame Only*
When you're maintaining an existing electrical distribution system, finding a replacement that matches the original equipment is essential. The SEDA24AT0060 is a 60-amp, 2-pole industrial molded case circuit breaker frame from the SE150 product line, designed for use in compatible electronic-trip breaker configurations. Featuring an SEHA frame type and an interrupting rating of 18kA at both 480VAC and 240VAC, this component provides the specified electrical characteristics for applications requiring this exact breaker configuration. Its dimensions—4.13 inches wide, 6.50 inches high, and 3.38 inches deep—give maintenance professionals the measurements needed to evaluate physical compatibility with existing equipment.
Key Features and Benefits
- 60-Amp Current Rating:
- 2-Pole Design:
- SEHA Frame Type:
- SE150 Product Line:
- Electronic Trip Configuration:
- 18kA Interrupting Rating at 480VAC:
- 18kA Interrupting Rating at 240VAC:
Technical Specifications
-
Part Number: SEDA24AT0060
-
Product Type: Industrial Molded Case Circuit Breaker Frame
-
Product Line: SE150
-
Frame Type: SEHA
-
Number of Poles: 2
-
Amperage: 60 Amps
-
A.I.C. Rating at 480VAC: 18kA
-
A.I.C. Rating at 240VAC: 18kA
-
Trip System: Electronic Trip Configuration
-
Supplied Component: FRAME ONLY
-
Height: 6.50 Inches
-
Width: 4.13 Inches
-
Depth: 3.38 Inches
-
Dimensions: 4.13"W x 6.50"H x 3.38"D
-
Shipping Weight: 8.5 lbs.
Material Compliance and Certifications
The SEDA24AT0060 SEHA frame is identified as part of the SE150 industrial molded case circuit breaker line. Specific material composition, UL listing details, ANSI/IEEE conformity, and other certifications for this exact part number have not been independently confirmed.
Where It Works Best
- Industrial Electrical Distribution Systems
- Commercial Electrical Infrastructure
- Legacy SE150 Equipment Maintenance
- Two-Pole Circuit Breaker Applications
- Scheduled Maintenance and Equipment Repair
