RC3860 - 60Amp Circuit Breaker

RC3860 - 60Amp Circuit Breaker

The RC3860 replacement circuit breaker is a 2-pole, 60-amp thermal-magnetic circuit breaker designed as a form, fit, and functional replacement for your applications that originally used the RC38-60. Built to fit the existing mounting location, this space-saving plug-on breaker helps you restore overcurrent and short-circuit protection in compatible legacy electrical distribution systems without requiring panel modifications. Its thermal-magnetic trip mechanism provides dependable protection against overloads and short circuits, while the compact footprint makes efficient use of available panel space. Built to last and manufactured to meet applicable industry requirements, this replacement breaker is well-suited for maintenance, repair, and replacement projects where preserving compatibility with existing equipment is important.

Key Features and Benefits

• Direct Replacement: Designed to fit the existing location of the RC38-60.
• 2-Pole Configuration: For 120/240VAC applications.
• 60 Amp Current Rating: For branch circuit protection.
• Thermal-Magnetic Trip Mechanism: Helps protect against overloads and short circuits.
• Space-Saving Plug-On Design: Maximizes available panel space.
• 10k A.I.C. Interrupting Rating: At 120/240VAC.
• Built to Last: For dependable operation in compatible electrical systems.
• Form, Fit, and Functional Compatibility: Designed for compatibility with existing installations.


Technical Specifications

• Part Number: RC3860

• Replacement For: RC38-60

• Type: RC38

• Circuit Breaker Style: Space-Saving Plug-On, Thermal-Magnetic

• Poles: 2

• Current Rating: 60 Amps

• Voltage Rating: 120/240VAC

• Interrupting Rating (A.I.C.): 10kA @ 120/240VAC

• Dimensions:
  • Height: 4.81 in.
  • Width: 0.75 in.
  • Depth: 2.50 in.

Material Compliance and Certifications

• Industry Standards: Manufactured to meet applicable industry standards for replacement circuit breakers.
• Compatibility: Designed for use in compatible electrical distribution equipment requiring an RC38-60 form, fit, and functional replacement.
• Installation Notice: Always confirm compatibility with your electrical panel and application before installation.
• Qualified Installation: Installation should be performed in accordance with applicable electrical codes and by qualified personnel.


Where It Works Best

• The RC3860 replacement circuit breaker is ideal for maintaining compatible residential and light commercial electrical panels that were originally designed for an RC38-60 breaker. It is well-suited for service replacements, panel maintenance, equipment repairs, and restoration projects where maintaining the existing panel configuration is the preferred solution. Its space-saving design makes it especially useful in installations where panel space is limited while providing the overcurrent protection required for compatible 120/240VAC branch circuits.
