RC3820 - 20Amp Circuit Breaker

RC3820 - 20Amp Circuit Breaker

When it's time to replace an RC3820 circuit breaker, getting the right fit is essential. This 20 Amp, 2-pole Type RC38 replacement circuit breaker is made to fit the same location as the original RC38-20, making it a practical choice for maintaining compatible electrical panels already in service. Built with a space-saving plug-on design, this breaker installs in the existing position without requiring changes to the panel when used in compatible equipment. The thermal-magnetic trip mechanism helps protect branch circuits by responding to both overloads and short circuits, while the 10kA interrupting rating at 120/240VAC makes it suitable for a wide range of residential, commercial, and light industrial applications. Whether you're replacing a breaker during routine maintenance or restoring an existing electrical panel, this replacement is built to last and provides the form, fit, and function needed for compatible RC38 installations.

Key Features and Benefits

• Replacement for RC3820 (RC38-20): Replacement for RC3820 (RC38-20) circuit breakers.
• Form, Fit, and Function Compatible: Compatible with the original breaker location.
• 20 Amp Current Rating: 20 Amp current rating.
• 2-Pole Design: For 120/240VAC applications.
• Space-Saving Plug-On Mounting: Space-saving plug-on mounting.
• Thermal-Magnetic Protection: Against overloads and short circuits.
• 10kA A.I.C. Interrupting Rating: 10kA A.I.C. interrupting rating.
• Built to Last: For continued service in compatible legacy electrical systems.


Technical Specifications

• Part Number: RC3820

• Type: RC38

• Poles: 2

• Amperage: 20 Amps

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kA @ 120/240VAC

• Trip Type: Thermal-Magnetic

• Mounting Style: Space-Saving Plug-On

• Dimensions:
  • Height: 4.81 in.
  • Width: 0.75 in.
  • Depth: 2.5 in.

Material Compliance and Certifications

• Industry Standards: Manufactured to meet applicable industry standards for form, fit, and function compatibility.
• Equipment Compatibility: Designed for use in compatible electrical equipment within its published ratings.
• Protection: Intended for overcurrent and short-circuit protection.
• Installation Notice: Verify compatibility with your panel before installation and follow applicable electrical codes.


Where It Works Best

• This RC3820 replacement breaker is intended for compatible Type RC38 panelboards found in residential, commercial, and light industrial electrical systems. If your existing panel uses an RC38-20 breaker, this replacement is designed to fit the original mounting location while maintaining the same electrical ratings.
