RC3815 - 15Amp Circuit Breaker

RC3815 - 15Amp Circuit Breaker

The RC3815 is a 2-pole, 15 Amp thermal-magnetic circuit breaker made for your applications that originally used the RC38-15. It is manufactured as a new aftermarket replacement with the same form, fit, and function, allowing it to install in the existing breaker position of compatible panels. This breaker uses a space-saving plug-on design and carries a 10 kA interrupting rating at 120/240 VAC. The thermal-magnetic trip mechanism protects against both overloads and short circuits. Its compact size also makes it a good match for panels where space-saving breakers are required. When you're replacing electrical components, compatibility matters as much as the electrical rating. Before installation, confirm that the panel is designed for an RC38-style breaker and that the voltage, amperage, and pole configuration match the original device. Built to last, the RC3815 is designed to maintain existing electrical systems without altering the original panel layout.

Key Features and Benefits

• Form, Fit, and Functional Replacement: For the RC38-15.
• Two-Pole, 15 Amp Rating: Two-pole breaker rated at 15 Amps.
• Thermal-Magnetic Trip Mechanism: Thermal-magnetic trip mechanism.
• Space-Saving Plug-On Construction: Space-saving plug-on construction.
• 10kA Interrupting Capacity: At 120/240VAC.
• Compatible RC38 Applications: Fits compatible RC38 panel applications.
• New Aftermarket Replacement: New aftermarket replacement.
• Built to Last: For continued service in existing electrical systems.


Technical Specifications

• Part Number: RC3815

• Type: RC38

• Replacement For: RC38-15

• Poles: 2

• Amperage: 15 Amps

• Voltage: 120/240VAC

• Interrupting Rating: 10kA

• Trip Mechanism: Thermal-Magnetic

• Mounting: Space-Saving Plug-On

• Dimensions:
  • Height: 4.81 in.
  • Width: 0.75 in.
  • Depth: 2.5 in.

Material Compliance and Certifications

• Replacement Applications: Manufactured for form, fit, and functional replacement applications.
• Durable Materials: Produced using durable materials intended for long service life.
• Compatible Electrical Systems: Designed for use in compatible electrical systems.
• Installation: Installation should comply with applicable electrical codes and be performed by qualified personnel.


Where It Works Best

• The RC3815 is intended for compatible residential and light commercial load centers that were originally equipped with an RC38-15 circuit breaker. It is commonly used during maintenance or repair work when an existing breaker needs to be replaced while keeping the original panel configuration intact.
