R3850 - Duplex 50/50 Circuit Breaker

R3850 - Duplex 50/50 Circuit Breaker

The R3850 is a 50 Amp duplex thermal-magnetic circuit breaker designed as a form, fit, and functional replacement for legacy electrical distribution systems that utilize Type R38 circuit breakers. This space-saving plug-on breaker allows two independent circuits to occupy a single breaker position, making it a practical solution for maintaining existing panel configurations without altering the panel layout. Built to last and manufactured to meet applicable industry standards, this replacement breaker provides dependable overcurrent and short-circuit protection for your compatible residential and light commercial electrical systems. Designed specifically to fit the original installation location of the R38-50, it offers an easy replacement option for maintaining the safe operation of existing equipment while preserving compatibility with legacy panelboards. Its thermal-magnetic trip mechanism helps you protect wiring and connected equipment by responding to both prolonged overloads and instantaneous short-circuit conditions, giving property owners and electricians confidence when servicing compatible electrical systems.

Key Features and Benefits

• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for Type R38-50 circuit breakers.
• Space-Saving Duplex Design: Space-saving duplex design allows two circuits in a single breaker space.
• 50 Amp Current Rating: 50 Amp current rating for compatible branch circuit applications.
• Thermal-Magnetic Trip Mechanism: The thermal-magnetic trip mechanism protects against overloads and short circuits.
• Plug-On Installation: Plug-on installation designed for compatible legacy panelboards.
• Built to Last: Built to last for continued service in existing electrical systems.
• Original Mounting Location: Designed to fit the original mounting location of the R38-50 without modifying the panel.

Technical Specifications

• Part Number: R3850
• Type: R38
• Circuit Breaker Style: Thermal-Magnetic, Plug-On
• Configuration: Duplex
• Amperage: 50 Amps
• Voltage: 120 VAC
• Interrupting Rating: 10kA @ 120 VAC
• Dimensions:
  • Height: 4.81 in.
  • Width: 0.75 in.
  • Depth: 2.50 in.

Material Compliance and Certifications

• Industry Standards: Manufactured to meet applicable industry standards for replacement circuit breakers.
• Electrical Code Compliance: Designed for installation in compatible electrical equipment in accordance with applicable electrical codes.
• Qualified Installation: Intended for use by qualified personnel following manufacturer and local code requirements.

Where It Works Best

• The R3850 is well-suited for servicing and maintaining existing residential and light-commercial electrical panels originally designed for Type R38 duplex circuit breakers. It is an excellent choice when replacing a breaker in compatible legacy panelboards where preserving the original panel configuration and breaker footprint is important. Its duplex, space-saving design makes it particularly useful in installations where maintaining available panel space is essential while providing reliable overcurrent protection for compatible branch circuits.
