Need a dependable 30-amp breaker for a residential, commercial, or equipment installation? The Square D QOU130 by Schneider Electric is worth a closer look. This single-pole miniature molded case circuit breaker is rated for 30 amps, operates on 120V and 120/240V AC circuits, and has a 10,000-amp (10kA) AC interrupting rating. It's also rated for 48VDC applications, subject to the manufacturer's requirements. The QOU130 is especially useful for its versatility. Unlike breakers designed exclusively for a particular plug-on panelboard, this unit-mounted model supports DIN rail, surface, and flush mounting arrangements with the appropriate mounting provisions. With thermal-magnetic circuit protection, convenient box-lug terminals, and Square D's VisiTrip indicator, you get a practical breaker for installations where the details really matter.

Key Features and Benefits

• 30 Amp, Single-Pole Design: Provides overcurrent protection for compatible 30A circuits without taking up unnecessary space.
• Thermal-Magnetic Protection: Responds to sustained overloads and short circuits, helping protect properly sized conductors and connected equipment.
• VisiTrip Indicator: A visible trip indication helps you spot a tripped breaker without having to guess which circuit was interrupted.
• Flexible Mounting: Supports DIN rail, surface, or flush mounting with the proper mounting hardware. Handy when a standard plug-on breaker doesn't meet the installation requirements.
• AC and DC Voltage Ratings: Suitable for specified 120V and 120/240V AC circuits, plus appropriately rated 48VDC applications.
• Copper and Aluminum Wire Compatibility: Slotted box-lug terminals accommodate the manufacturer's specified 14 AWG through 2 AWG conductor range.

Technical Specifications

• Manufacturer: Schneider Electric

• Brand: Square D

• Catalog Number: QOU130

• Product Series: QOU

• Product Type: Miniature Molded Case Circuit Breaker

• Breaker Type: Standard

• Rated Current: 30 Amps

• Number of Poles: 1 Pole (1P)

• AC Operating Voltage: 120V AC / 120/240V AC

• DC Operating Voltage: 48V DC

• AC Interrupting Rating: 10kA at 120V AC and 120/240V AC

• Trip Mechanism: Thermal-Magnetic

• Trip Indication: VisiTrip

• Application Rating: HACR

• Mounting Mode: Unit Mount

• Mounting Options: DIN Rail, Surface Mount, or Flush Mount with Appropriate Mounting Provisions

• Line Connection: Slotted Box Lug

• Load Connection: Slotted Box Lug

• Compatible Conductors: Copper or Aluminum

• Wire Size Range: 14 AWG to 2 AWG

• Terminal Tightening Torque: 45 lbf-in (5.08 N·m)

• Height: 4.05 in (102.87 mm)

• Width: 0.75 in (19.05 mm)

• Depth: 2.95 in (74.93 mm)

• Manufacturer-Listed Certifications: UL Listed, CSA, IEC


Material Compliance and Certifications

You don't want to rely on guesswork for electrical protection. The Square D QOU130 carries manufacturer-listed UL Listed and CSA certifications, and Schneider Electric also identifies IEC in its product certification information. According to the manufacturer, UL and CSA have verified QOU miniature circuit breakers against their published specifications.

Where It Works Best

• Residential and Commercial Electrical Installations

• Heating, Air-Conditioning, and Refrigeration Equipment

• Control Panels and Equipment Enclosures

• Low-Voltage DC Applications

• Replacing an Existing QOU130 Breaker

• Installations Where Trip Indication Helps

• A Practical Choice When the Specifications Match
