QOU120 - 20 Amp Circuit Breaker

QOU120 - 20 Amp Circuit Breaker

The QOU120 is a 20 Amp, single-pole Type QOU circuit breaker used to protect 120VAC electrical circuits from overloads and short circuits. It features a thermal magnetic trip unit, allowing it to respond to both sustained overload conditions and higher fault currents before damage can occur to the circuit. This breaker uses a cable-in/cable-out connection, making it suitable for compatible electrical distribution equipment that requires direct cable terminations. Its compact design also helps when working in panels where space is limited. The 10kA interrupting rating at 120VAC allows the breaker to safely interrupt fault currents within its rated capacity. Whether you're replacing an existing breaker or maintaining electrical equipment, the QOU120 is a dependable option for compatible systems.

Key Features and Benefits

• 20 Amp Current Rating: 20 Amp current rating.
• Single-Pole Configuration: Single-pole configuration.
• Type QOU Circuit Breaker: Type QOU circuit breaker.
• Thermal Magnetic Trip Protection: Thermal magnetic trip protection.
• Cable-In/Cable-Out Connection: Cable-in/cable-out connection.
• 10kA Interrupting Capacity: 10kA interrupting capacity at 120VAC.
• Compact Size: Compact size for compatible panelboards and electrical equipment.
• Circuit Protection: Helps protect circuits from overloads and short circuits.


Technical Specifications

• Part Number: QOU120

• Type: QOU

• Poles: 1

• Amperage: 20A

• Voltage Rating: 120VAC

• Interrupting Capacity: 10kA @ 120VAC

• Trip Type: Thermal Magnetic

• Connection Type: Cable-In / Cable-Out

• Dimensions:
  • Height: 4.0 in.
  • Width: 0.75 in.
  • Depth: 2.38 in.

Material Compliance and Certifications

• Industry Standards: The QOU120 is manufactured for use in electrical power distribution systems and is intended for installation in compatible equipment.
• Installation Requirements: Installation should be completed by qualified personnel in accordance with applicable electrical codes and the equipment manufacturer's instructions.


Where It Works Best

• The QOU120 is commonly found in applications such as: Commercial buildings, Industrial facilities, Office buildings, Retail spaces, Residential electrical systems, Control panels, Branch circuit protection. When installed in compatible equipment, the QOU120 provides reliable protection for 120VAC branch circuits, helping reduce the risk of damage caused by overloads and short-circuit conditions.
