QOM2200VH - 200 Amp Circuit Breaker

QOM2200VH - 200 Amp Circuit Breaker

The QOM2200VH is a 200-amp, 2-pole main circuit breaker used in compatible residential electrical panels. Its job is straightforward: protect the electrical system by shutting off power if an overload or short circuit occurs. That protection helps reduce the risk of damage to wiring and connected equipment while keeping the panel operating as intended. This breaker uses a thermal magnetic trip mechanism, combining protection against long-term overloads with a fast response to high fault currents. It also carries a 22kA interrupting rating at 240VAC, making it suitable for residential electrical systems that require a main bolt-in breaker with this level of fault protection. The bolt-in mounting design provides a secure connection within compatible load centers, and the molded-case construction is designed for everyday residential service. If you're replacing an existing breaker, matching the part number, amperage, pole configuration, and panel compatibility is essential before installation.

Key Features and Benefits

• 200 Amp main residential circuit breaker: Provides main circuit protection for compatible residential electrical systems.
• 2-pole design: Designed for 240VAC applications.
• Thermal magnetic trip protection: Protects against overloads and short circuits.
• 22kA interrupting capacity at 240VAC: Provides high fault-current protection.
• Bolt-in mounting: Designed for compatible residential load centers.
• Molded case construction: Built for dependable everyday use.


Technical Specifications

• Part Number: QOM2200VH

• Type: QOM

• Breaker Style: Main Residential Bolt-In, Molded Case, Thermal Magnetic

• Poles: 2

• Amperage: 200A

• Voltage Rating: 240VAC

• Interrupting Capacity: 22kA @ 240VAC

• Dimensions:
  • Height: 5.75 in.
  • Width: 5.13 in.
  • Depth: 3.06 in.

Material Compliance and Certifications

• Molded Case Construction: Molded case circuit breaker for residential electrical applications.
• Industry Standards: Manufactured to applicable industry standards for circuit breaker performance.
• Installation Requirements: Install only in compatible equipment and in accordance with local electrical codes and the manufacturer's instructions.


Where It Works Best

• The QOM2200VH is intended for compatible residential load centers that require a 200-amp, 2-pole bolt-in main breaker. It's commonly used when replacing a failed main breaker, upgrading an electrical panel, or performing routine maintenance on residential electrical systems. Electricians and maintenance professionals also use it when restoring existing panels that require this specific breaker type.
