QOM2175VH - 175 Amp Circuit Breaker

QOM2175VH - 175 Amp Circuit Breaker

The Square D QOM2175VH is a 175 amp, 2-pole main breaker made for QO and Homeline load centers. Rated for 120/240VAC with a 22kA interrupting capacity, it serves as the primary disconnect and overcurrent protection device in residential, commercial, and light industrial panels.

This breaker is designed with a thermal-magnetic trip mechanism and includes a Visi-Trip® indicator that lets you quickly see if the breaker has tripped. The bolt-on design keeps it secure in the panel while providing reliable operation over time. Whether you’re replacing an existing main breaker or installing a new panel, the QOM2175VH fits directly into compatible QO or Homeline systems and provides the proper ratings for branch circuits, HVAC equipment, and general power distribution.

Key Features and Benefits

• 175A, 2-pole main breaker: 175A, 2-pole main breaker.
• Rated for 120/240VAC single-phase systems: Rated for 120/240VAC single-phase systems.
• 22kA interrupting rating: 22kA interrupting rating.
• Thermal-magnetic overcurrent protection: Thermal-magnetic overcurrent protection.
• Bolt-on mounting for secure installation: Bolt-on mounting for secure installation.
• Visi-Trip® visual trip indicator: Visi-Trip® visual trip indicator.
• All poles open simultaneously during a fault: All poles open simultaneously during a fault.
• Compatible with QO and Homeline load centers: Compatible with QO and Homeline load centers.


Technical Specifications

• Manufacturer: Square D

• Catalog Number: QOM2175VH

• Series: QO

• Rated Current: 175A

• Poles: 2

• Voltage Rating: 120/240VAC

• Mounting Type: Bolt-On

• Circuit Breaker Type: Standard

• Electrical Connection: Lugs

• Wire Size Range: AWG 4–300 kcmil Copper or Aluminum

• Tightening Torque: 247.8 lb-in (28 N·m)

• Dimensions:
  • Height: 5.6 in
  • Width: 5.08 in
  • Depth: 3.6 in
• Weight: 2.65 lb

• Ambient Temperature Rating: 104°F (40°C)


Material Compliance and Certifications

• UL Listed: UL Listed (UL File E84967).
• CSA Certified: CSA Certified.


Where It Works Best

• QO and Homeline load centers
• Residential main panels
• Commercial electrical distribution
• HVAC equipment protection
• Branch circuit protection
• Electrical panel upgrades and replacements
• New installations and retrofit projects
