QOM2125VH - 125 Amp Circuit Breaker

QOM2125VH - 125 Amp Circuit Breaker

When dependable main circuit protection matters, the QOM2125VH delivers the performance needed for residential electrical systems. This 150-amp, 2-pole molded case circuit breaker is built as a main residential bolt-in breaker and uses a thermal magnetic trip mechanism to respond to both sustained overloads and sudden short circuits. With an interrupting rating of 22kA at 240VAC, it provides the level of protection required for many residential service applications where higher fault current capacity is important. Its bolt-in construction creates a secure connection inside compatible electrical equipment, making it a practical replacement for worn or damaged breakers or a dependable choice for new installations. Whether you're updating an older electrical panel or completing a new residential project, the QOM2125VH offers the reliability electricians expect from a main service breaker.

Key Features and Benefits

• 150 amp continuous current rating: Provides dependable current capacity for residential electrical systems.
• 2-pole configuration: Designed for 240VAC systems.
• Thermal magnetic trip unit: Responds to overloads and short circuits.
• 22kA interrupting capacity at 240VAC: Provides dependable fault current protection.
• Main residential bolt-in mounting: Offers a secure installation.
• Molded case construction: Built for everyday service.
• Ideal for residential electrical projects: A solid choice for residential panel upgrades, repairs, and new installations.


Technical Specifications

• Part Number: QOM2125VH

• Type: QOM

• Breaker Style: Main Residential Bolt-In, Molded Case, Thermal Magnetic

• Poles: 2

• Amperage: 150A

• Voltage: 240VAC

• Interrupting Rating: 22kA @ 240VAC

• Dimensions:
  • Height: 5.75 in.
  • Width: 5.13 in.
  • Depth: 3.06 in.

Material Compliance and Certifications

• Molded Case Construction: The QOM2125VH is a molded case thermal magnetic circuit breaker intended for use in compatible residential electrical equipment.
• Installation Requirements: It should be installed according to applicable electrical codes and the equipment manufacturer's installation requirements.
• Application Guidance: Using the correct breaker for the intended application helps support safe and reliable operation.


Where It Works Best

• The QOM2125VH is commonly used as the main breaker in residential electrical systems requiring a 150-amp, 2-pole bolt-in breaker. Typical applications include:
  • Residential service entrance equipment
  • Main breaker load centers
  • Home electrical panel replacements
  • Service upgrades and remodeling projects
  • New residential construction
  • Electrical systems requiring a 22kA interrupting rating at 240VAC
  Built for everyday residential service, the QOM2125VH provides dependable overcurrent protection while helping keep electrical distribution systems operating safely and efficiently.
