QOB325 - 25 Amp Circuit Breaker

QOB325 - 25 Amp Circuit Breaker

The QOB325 is a 25-amp, 3-pole bolt-on circuit breaker used to protect your three-phase electrical circuits from overloads and short circuits. Built for use in compatible Type QOB panelboards, its bolt-on mounting helps you to keep the breaker firmly secured to the panel, making it a popular choice in commercial and industrial electrical systems. Rated 10kA at 240VAC, the QOB325 is commonly installed in distribution panels serving lighting, HVAC equipment, machinery, and other branch circuits. Its compact size makes it a practical replacement when an existing breaker needs to be swapped out or when adding circuits to compatible equipment. For electricians and maintenance teams, it's simply a reliable breaker that gets the job done without unnecessary complexity.

Key Features and Benefits

• 25 Amp Continuous Current Rating: 25 amp continuous current rating.
• Three-Pole Breaker: Three-pole breaker for three-phase applications.
• Bolt-On Installation: Bolt-on installation for a secure panel connection.
• 10kA Interrupting Rating: 10kA interrupting rating at 240VAC.
• Type QOB Compatibility: Compatible with Type QOB panelboards.
• Branch Circuit Protection: Helps protect branch circuits from overloads and short-circuit faults.
• Compact Design: Easier installation and replacement.


Technical Specifications

• Part Number: QOB325

• Type: QOB

• Mounting: Bolt-On

• Poles: 3

• Amperage: 25A

• Voltage: 240VAC

• Interrupting Rating: 10kA @ 240VAC

• Dimensions:
  • Height: 3.0 in.
  • Width: 2.25 in.
  • Depth: 2.5 in.

Material Compliance and Certifications

• Industry Standards: The QOB325 is manufactured in accordance with applicable industry standards for molded-case circuit breakers.
• Installation Requirements: Installation should be completed with compatible equipment and in accordance with the National Electrical Code (NEC), local electrical codes, and the equipment manufacturer's recommendations.


Where It Works Best

• The QOB325 is commonly found in: Commercial buildings, Manufacturing facilities, Schools and universities, Office buildings, Retail spaces, Electrical distribution panels, HVAC equipment, Three-phase branch circuit applications requiring a compatible Type QOB breaker. Whether you're replacing a worn breaker or expanding an existing electrical panel, the QOB325 offers a straightforward solution for applications that require a 25-amp, 3-pole, bolt-on circuit breaker.
