QOB1151021 - 15A Circuit Breaker

QOB1151021 15A Circuit Breaker

This high-performance miniature circuit breaker, part of the renowned QO series, is designed to deliver exceptional protection and durability. Rated at 15 amps, this single-pole breaker operates at 120/240VAC, making it ideal for a wide range of residential and commercial applications. The QOB1151021 stands out with its integrated AC shunt trip feature, providing an added layer of protection by enabling remote tripping of the circuit.

Key Features and Benefits:

• Comprehensive Overcurrent Protection: The QOB1151021 employs a thermal magnetic mechanism for rapid and precise response to overcurrent conditions, ensuring your electrical system remains safeguarded.
• VisiTrip Indicator: This feature provides a clear visual indication when the breaker has tripped, allowing for quick identification and troubleshooting.
• AC Shunt Trip: Allows for remote tripping, enhancing safety by enabling the circuit to be interrupted from a distance in critical situations.
• Versatile Application: Suitable for both AC and DC systems, providing flexibility for various electrical setups.

Technical Specifications:

• Current Rating: 15A
• Voltage Rating: 120/240V AC
• Interrupting Capacity: 10kA at 120/240V AC
• Mounting Type: Bolt-on
• Number of Poles: 1
• Shunt Trip Voltage: 120/208/240V AC
• Wire Size: Compatible with AWG 14 to AWG 8 (copper or aluminum)
• Tightening Torque: 35.4 lbf.in (4 N.m)
• Dimensions: Height - 3.0 inches, Width - 1.5 inches, Depth - 2.9 inches
• Weight: 0.659 lbs

Material Compliance and Certifications:

• UL Listed: Under UL File E84967
• CSA Certified: Under CSA Master Contract 153555
• RoHS/REACh Compliant: Adheres to strict environmental regulations for hazardous substances, minimizing ecological impact.
• Green Premium Label: Reflects Schneider Electric‰۪s commitment to sustainability, ensuring compliance with the latest environmental standards and offering transparency on environmental impacts.

Suitability:

• The QOB1151021 Circuit Breaker is perfect for a variety of applications, providing reliable protection for residential and light commercial electrical systems. Its high interrupting capacity and durable performance make it a preferred choice for electricians, contractors, and maintenance professionals seeking advanced circuit protection solutions.
