QO250GFI - 50 Amp Circuit Breaker

QO250GFI - 50 Amp Circuit Breaker

When you’re looking for reliable protection for your home or commercial electrical system, the Schneider Electric QO250GFI Circuit Breaker is a solid choice. This 2-pole breaker is built to handle 50 Amps at 120/240 VAC, giving you dependable overcurrent and ground fault protection in one compact unit. It’s designed to make installation simple, and with its 6mA ground fault protection and included pigtail connection, you’ll have extra safety built right in.

Key Features and Benefits

• Added Safety: Ground fault protection kicks in fast to prevent shocks and electrical fires.
• Dependable Power Handling: Rated for 50 Amps with a 10kA interrupting capacity, it helps safeguard circuits from overloads and shorts.
• Easy to Spot Trips: The VisiTrip® indicator lets you know instantly when the breaker has tripped, saving time during maintenance.
• Straightforward Installation: Plug-in design with a pre-attached pigtail means you can get it installed quickly and easily.
• Built to Last: Made with durable, compliant materials for years of safe operation.

Technical Specifications

• Amperage: 50 Amp

• Voltage: 120/240 VAC

• Poles: 2

• Interrupting Capacity: 10kA

• Mounting: Plug-in

• Ground Fault Protection: Class A, 6mA with pigtail

• Wire Sizes: Aluminum AWG 12–4, Copper AWG 14–6

• Torque: 44.3 lbf.in (5 N·m)

• Dimensions:
  • Height: 4.1 inches
  • Width: 1.5 inches
  • Depth: 2.9 inches
• Weight: 1 lb (0.454 kg)


Material Compliance and Certifications

• Compliance: RoHS and REACh compliant and contains no hazardous materials.
• Certifications: UL Listed and CSA Certified, meeting strict safety standards you can trust.


Suitability

• Perfect for residential panels or light commercial settings where safety is critical. Whether you’re replacing an old breaker or setting up a new installation, the QO250GFI gives you peace of mind with reliable, everyday protection.
