QO225 **Older Style** - 25 Amp Circuit Breaker

QO225 **Older Style** - 25 Amp Circuit Breaker

The QO225 Older Style Plug-On Circuit Breaker is a 2-pole, 25-amp circuit breaker designed for use in your compatible Type QO load centers and panelboards. Rated for 120/240VAC with a 10kA A.I.C. interrupting rating, this breaker provides branch circuit protection by helping you guard electrical systems against overloads and short circuits. Its plug-on design allows for proper installation in compatible panels, making it a practical form, fit, and functional replacement for maintaining existing electrical distribution systems. Built to last, the QO225 Older Style breaker is well-suited for residential and light commercial applications where maintaining compatibility with legacy equipment is important.

Key Features and Benefits

• 2-Pole Configuration: 2-pole configuration for 120/240VAC branch circuits.
• 25 Amp Current Rating: 25-amp current rating.
• Type QO Plug-On Design: Type QO plug-on design for compatible load centers and panelboards.
• 10kA A.I.C. Interrupting Rating: 10kA A.I.C. interrupting rating at 120/240VAC.
• Circuit Protection: Helps protect electrical circuits from overloads and short circuits.
• Replacement Design: Designed as a form, fit, and functional replacement for compatible older-style installations.
• Compact Design: Compact design for straightforward installation in compatible equipment.
• Built to Last: Built to last for continued service in existing electrical systems.


Technical Specifications

• Part Number: QO225 Older Style

• Type: QO

• Mounting Style: Plug-On

• Poles: 2

• Amperes: 25A

• Voltage Rating: 120/240VAC

• A.I.C. Rating: 10kA @ 120/240VAC

• Dimensions:
  • Height: 3.0 in.
  • Width: 1.5 in.
  • Depth: 2.5 in.

Material Compliance and Certifications

• Industry Standards: Designed for use in compatible Type QO electrical distribution equipment. Manufactured to meet applicable industry standards for molded case circuit breakers when originally produced.
• Installation Requirements: Intended for installation and use in accordance with applicable national and local electrical codes. Verify compatibility with the existing panel or load center before installation.


Where It Works Best

• The QO225 Older Style 2-Pole 25-Amp Plug-On Circuit Breaker is well-suited for maintaining compatible residential and light commercial electrical systems that utilize Type QO load centers or panelboards. It is commonly used to protect 120/240 VAC branch circuits serving equipment and appliances that require a 2-pole, 25-amp breaker. This breaker is intended as a form, fit, and functional replacement where matching the original breaker type and electrical ratings is essential for the continued operation of legacy electrical installations.
