QO2125VH - 125 Amp Circuit Breaker

QO2125VH - 125 Amp Circuit Breaker

The Schneider Electric QO2125VH is a dependable circuit breaker designed to keep your electrical system safe and running smoothly. Built for both residential and light commercial applications, this breaker delivers 125 amps of protection at 120/240 volts AC. With a 22kA interrupting capacity, it provides strong defense against overloads and short circuits. Installation is quick and straightforward thanks to its plug-in design, and the VisiTrip® indicator makes it easy to see when the breaker has tripped. Whether you’re replacing an old breaker or adding capacity to a panel, this is a solid, long-lasting choice you can count on.

Key Features and Benefits

• Reliable Safety: Protects your electrical circuits with a 22kA fault interrupt rating, helping prevent damage from overloads and short circuits.
• Simple Troubleshooting: The built-in VisiTrip® indicator lets you know immediately when the breaker has tripped.
• Straightforward Installation: Plug-in mounting makes setup faster and easier for electricians and DIY installers alike.
• Environmentally Responsible: Part of Schneider’s Green Premium™ line, fully compliant with RoHS and REACh standards.
• Consistent Performance: Quick-make, quick-break toggle ensures a fast response to faults and dependable operation.
• Made to Last: Constructed from quality materials designed for durability and long-term use.


Technical Specifications

• Amperage: 125A

• Poles: 2

• Voltage: 120/240 VAC

• Interrupting Rating: 22kA

• Mounting: Plug-in

• Breaker Type: Standard

• Dimensions:
  • Height: 3.5 inches
  • Width: 1.5 inches
  • Depth: 2.9 inches
• Weight: 0.701 lb

• Wire Size: AWG 4 – AWG 2/0 (Copper or Aluminum)

• Torque: 49.6 lbf.in (5.6 N.m)


Material Compliance and Certifications

• Green Premium™ Certified: Designed to reduce environmental impact, free of hazardous substances.
• Safety Approvals: UL Listed and CSA Certified, meeting strict safety requirements.

• Ambient Temperature: Rated for environments up to 104°F (40°C).


Suitability

• Perfect for protecting circuits in homes, workshops, and small commercial buildings, the QO2125VH is a go-to choice for panel upgrades, replacements, or new installations that need dependable high-amperage protection.
