QO2100VH - 100 Amp Circuit Breaker

QO2100VH - 100 Amp Circuit Breaker

The QO2100VH is a 2-pole, 100-amp plug-on circuit breaker for use in your compatible QO series panelboards. Rated for 120/240VAC with a 22kA interrupting capacity, it protects electrical circuits from overloads and short circuits in residential, commercial, and light industrial electrical systems. This breaker installs with a standard plug-on connection, making it a suitable replacement for an existing unit or for use in new panel installations that require a Type QO-VH breaker. Its compact design fits within standard panel layouts while providing the electrical protection required for compatible 120/240VAC applications. Before installation, always confirm that the breaker type, amperage, voltage rating, and interrupting capacity match the requirements of your electrical system.

Key Features and Benefits

• 100 Amp Current Rating: 100 amp current rating.
• Two-Pole Design: Two-pole design.
• Plug-On Mounting: Plug-on mounting.
• Type QO-VH Circuit Breaker: Type QO-VH circuit breaker.
• Rated for 120/240VAC Systems: Rated for 120/240VAC systems.
• 22kA Interrupting Rating: 22kA interrupting rating.
• Circuit Protection: Helps protect circuits from overloads and short circuits.
• Compatible Panelboards: Fits compatible QO series panelboards.


Technical Specifications

• Part Number: QO2100VH

• Type: QO-VH

• Mounting Style: Plug-On

• Poles: 2

• Current Rating: 100 Amps

• Voltage Rating: 120/240VAC

• Interrupting Rating: 22kA @ 120/240VAC

• Dimensions:
  • Height: 3.5 in.
  • Width: 1.5 in.
  • Depth: 2.5 in.

Material Compliance and Certifications

• Installation Requirements: Install this circuit breaker only in compatible equipment and in accordance with the manufacturer's instructions and applicable electrical codes. Verify compatibility before replacing or installing any electrical component.

Where It Works Best

• The QO2100VH is commonly used in compatible QO load centers and panelboards serving residential, commercial, and light industrial applications. It is intended for circuits requiring a 2-pole, 100-amp breaker rated for 120/240 VAC with a 22 kA interrupting capacity.
