QO1201021 - 20 Amp Circuit Breaker

QO1201021 - 20 Amp Circuit Breaker

The Schneider Electric QO1201021 Circuit Breaker is an exceptional choice for ensuring the safety and reliability of your electrical systems. This miniature circuit breaker is part of the esteemed QO series, known for its durability and high performance. Rated at 20Amp, it operates at 120/240VAC, making it suitable for a wide range of residential, commercial, and light industrial applications. This 1-pole breaker features a 10kA interrupting capacity and includes a built-in AC shunt trip, enhancing its protective capabilities. The plug-in mounting design allows for quick and easy installation, making it a convenient choice for both new setups and upgrades.

Key Features and Benefits:

• AC Shunt Trip: Includes an AC shunt trip, providing additional protection by allowing remote tripping of the breaker.
• Trip-Free Mechanism: Ensures the breaker cannot be manually overridden during fault conditions, providing consistent and reliable protection.
• VisiTrip Indicator: Offers a visual indication when the breaker has tripped, allowing for quick identification and resolution of issues.
• High Interrupting Capacity: Delivers robust protection with a 10kA rating at 120/240VAC, suitable for demanding environments.
• Quick-Make, Quick-Break Action: Ensures swift and efficient operation, enhancing overall system safety and reliability.
• Plug-In Mounting: Facilitates easy and convenient installation, reducing setup time and effort.

Technical Specifications:

• Current Rating: 20Amperes
• Voltage Rating: 120/240V AC
• Poles: 1
• Interrupting Capacity: 10kA at 120/240V AC
• Mounting Type: Plug-in
• Wire Size: AWG 14 to AWG 8 copper or aluminum
• Tightening Torque: 35.4 lbf.in (4 N.m)
• Dimensions: 3.0 in (height) x 1.5 in (width) x 2.9 in (depth)
• Weight: 0.639 lbs (0.290 kg)

Material Compliance and Certifications:

• The Schneider Electric QO1201021 Circuit Breaker complies with essential safety and environmental standards. It is UL Listed under UL File E84967 and CSA Certified under CSA Master Contract 153555, ensuring adherence to stringent safety regulations. Additionally, it meets the RoHS directive and REACh regulation, highlighting its commitment to environmental sustainability. This circuit breaker is also mercury-free and complies with various international environmental standards, making it an eco-friendly choice for your electrical systems.

Suitability:

• Ideal for residential, commercial, and light industrial applications, the Schneider Electric QO1201021 Circuit Breaker provides reliable protection for your electrical circuits. Its advanced shunt trip feature, high interrupting capacity, and robust design make it an excellent choice for ensuring the safety and efficiency of your electrical systems. Whether for new installations or upgrades, this circuit breaker delivers optimal performance and peace of mind.
