QN2200H - 200Amp Circuit Breaker

QN2200H - 200Amp Circuit Breaker

The QN2200H is a 2-pole, 200-amp plug-in circuit breaker for electrical panels that accept Type QN breakers. It is rated for 120/240VAC with a 22kA interrupting capacity and uses a thermal magnetic trip to respond to overloads and short circuits.

This model is intended for residential main applications and requires four panel spaces. It is also rated for 50/60Hz operation, 40°C ambient conditions, and carries an HACR Type rating for compatible heating and air conditioning equipment. When you're replacing an existing breaker, matching the original Type, amp rating, voltage, and panel compatibility helps ensure proper fit and operation. Built to last, the QN2200H is intended as a form, fit, and functional replacement for equipment designed to use this breaker style.

Key Features and Benefits

• Part Number: Part number: QN2200H
• Type QN Plug-In Design: Type QN plug-in design
• 200 Amp Rating: 200 Amp rating
• Two Poles: Two poles
• Thermal Magnetic Trip Mechanism: Thermal magnetic trip mechanism
• 22kA Interrupting Rating: 22kA interrupting rating at 120/240VAC
• 50/60Hz Operation: 50/60Hz operation
• 40°C Ambient Rating: 40°C ambient rating
• HACR Type-Rated: HACR Type-rated
• Panel Space Requirement: Occupies four panel spaces
• Built to Last: Built to last for compatible replacement applications


Technical Specifications

• Part Number: QN2200H

• Type: QN

• Poles: 2

• Amperage: 200A

• Voltage: 120/240VAC

• Interrupting Rating: 22kA @ 120/240VAC

• Trip Mechanism: Thermal, Magnetic

• Mounting Style: Plug-In

• Frequency: 50/60Hz

• Ambient Temperature: 40°C

• HACR Rated: Yes

• Application: Residential Main

• Panel Spaces Required: 4

• Dimensions:
  • Height: 6.44 in.
  • Width: 2.00 in.
  • Depth: 2.38 in.

Material Compliance and Certifications

• HACR Rating: The QN2200H is HACR Type-rated and designed for use on 120/240 VAC, 50/60Hz electrical systems.
• Overcurrent Protection: It provides thermal magnetic overcurrent protection and should only be installed in equipment designed to accept a Type QN breaker with matching electrical ratings.
• Compatibility Verification: Always verify compatibility before installation.


Where It Works Best

• This breaker is commonly used in compatible residential load centers where a Type QN 200A two-pole main breaker is specified. It is intended for applications requiring a plug-in installation, 22 kA interrupting capacity, and a four-panel-space configuration.
