QN2200 - 200Amp Circuit Breaker

QN2200 - 200Amp Circuit Breaker

When your electrical system demands dependable main breaker protection, the QN2200 2-pole 200 amp circuit breaker is built to deliver the performance you need. Designed for compatible residential load centers, this Type QN plug-in main breaker provides reliable protection against overloads and short circuits through its proven thermal magnetic trip mechanism. Whether you're replacing a worn breaker during maintenance or completing a panel upgrade, the QN2200 helps keep your electrical distribution system operating safely and efficiently.

Rated for 120/240VAC applications with a 10kA interrupting capacity, this breaker is well-suited for residential electrical systems that require a high-capacity main disconnect. Its plug-in design makes installation straightforward in compatible panels, while the 200 amp rating provides the capacity needed for today's homes with greater electrical demands. The HACR rating also makes it suitable for approved heating and air conditioning applications, giving electricians and homeowners added versatility when servicing compatible equipment.

Choosing the correct circuit breaker is about more than matching the amperage. It's equally important to select the right breaker type for your panel. The QN2200 is engineered specifically for installations requiring a Type QN, 2-pole, 200-amp plug-in residential main circuit breaker, helping to ensure proper fit, dependable operation, and long-term electrical protection when installed in compatible equipment.

Key Features and Benefits

• 200 amp continuous current rating: For residential main service applications.
• 2-pole configuration: Designed for 120/240VAC electrical systems.
• Thermal magnetic trip mechanism: Provides dependable protection against overloads and short circuits.
• 10kA A.I.C. rating: Helps safely interrupt available fault current.
• Plug-in mounting design: Allows for quick installation in compatible load centers.
• Residential main circuit breaker: Designed for use as the primary service disconnect in compatible panels.
• HACR Type-rated: For approved heating, air conditioning, and refrigeration equipment.
• Operating conditions: Operates at 40°C ambient temperature and 50/60Hz.
• Panel space requirement: Requires 4 panel spaces.

Technical Specifications

• Part Number: QN2200
• Type: QN
• Poles: 2
• Amperage: 200 Amps
• Voltage Rating: 120/240VAC
• Interrupting Capacity: 10kA
• Trip Mechanism: Thermal, Magnetic
• Mounting Style: Plug-In
• Application: Residential Main
• Frequency: 50/60Hz
• Ambient Temperature: 40°C
• HACR Rated: Yes
• Panel Spaces Required: 4
• Height: 6.44 in.
• Width: 2.00 in.
• Depth: 2.38 in.

Material Compliance and Certifications

• HACR Type-rated: Heating, Air Conditioning, and Refrigeration Type-rated.
• Thermal magnetic trip protection: For dependable overcurrent protection.
• Compatibility: Manufactured for use in compatible electrical distribution equipment. Always verify panel compatibility and follow all applicable electrical codes and manufacturer installation requirements.

Where It Works Best

• The QN2200 is ideal for residential electrical service panels that require a 200-amp Type QN plug-in main breaker. It's commonly used for panel replacements, electrical service upgrades, preventative maintenance, and repair projects where a compatible 2-pole residential main breaker is specified. It's also an excellent choice for residential HVAC electrical installations that require an HACR-rated breaker.
