QN2175 - 175Amp Circuit Breaker

QN2175 - 175Amp Circuit Breaker

The QN2175 is a 2-pole, 175-amp Type QN plug-in thermal magnetic circuit breaker designed to provide dependable overcurrent and short-circuit protection for your compatible residential main load centers. Rated for 120/240VAC with a 10kA A.I.C. interrupting capacity, this breaker helps you to protect electrical distribution systems from damage caused by overloads and fault currents while supporting safe, reliable operation. Its thermal-magnetic trip mechanism provides responsive protection against both sustained overload conditions and instantaneous short circuits, making it well-suited for your demanding residential electrical applications. Built for 40°C operation and 50/60Hz systems, the QN2175 also carries an HACR Type rating, making it suitable for approved heating, air conditioning, and refrigeration equipment. The plug-in design simplifies installation in compatible panels, while the breaker requires four panel spaces to accommodate its high current capacity. Whether you're replacing an existing breaker during maintenance or completing a panel upgrade, the QN2175 offers the performance and protection expected for high-amperage residential electrical systems.

Key Features and Benefits

• Part Number: QN2175
• 175 Amp current rating: For high-capacity residential main applications.
• 2-pole configuration: For 120/240VAC electrical systems.
• Thermal magnetic trip unit: Protects against overloads and short circuits.
• 10kA A.I.C. interrupting rating: At 120/240VAC.
• Plug-in design: Allows for straightforward installation in compatible load centers.
• HACR Type-rated: For approved heating, air conditioning, and refrigeration equipment.
• Designed for 40°C ambient operating conditions:
• Operates on 50/60Hz electrical systems:
• Panel space requirement: Requires 4 panel spaces for installation.


Technical Specifications

• Part Number: QN2175

• Type: QN

• Poles: 2

• Amperage: 175 Amps

• Voltage Rating: 120/240VAC

• Interrupting Rating (A.I.C.): 10kA @ 120/240VAC

• Trip Mechanism: Thermal, Magnetic

• Mounting Style: Plug-In

• Frequency: 50/60Hz

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Panel Space Required: 4 Spaces

• Dimensions:
  • Height: 6.44 in.
  • Width: 2.00 in.
  • Depth: 2.38 in.

Material Compliance and Certifications

• HACR Type-rated: For approved heating, air conditioning, and refrigeration applications.
• Electrical system compatibility: Designed for operation on 120/240VAC, 50/60Hz electrical systems.
• Operating environment: Engineered for use in compatible electrical distribution equipment operating in 40°C ambient conditions.


Where It Works Best

• The QN2175 is ideal for residential main electrical panels and other compatible load centers that require a 175-amp, 2-pole plug-in circuit breaker. It is well-suited for protecting high-capacity feeder circuits and residential service equipment where dependable overload and short-circuit protection is essential. Its HACR rating also makes it an appropriate choice for qualifying HVAC and refrigeration installations that require a breaker with reliable thermal magnetic protection.
