QN2150R - 150Amp Circuit Breaker

QN2150R - 150Amp Circuit Breaker

If you need a 150 Amp residential main circuit breaker with a reversed handle configuration, the QN2150R is built for that job. This 2-pole Type QNR breaker installs using a plug-in connection and provides dependable protection against overloads and short circuits with its thermal magnetic trip system. Rated for 120/240VAC with a 10kA interrupting capacity, it's intended for compatible residential electrical panels where a high-amperage main breaker is required.

The QN2150R is also HACR rated, making it suitable for residential HVAC applications as well as general electrical distribution. It operates at 50/60Hz, is rated for use in environments up to 40°C, and occupies four panel spaces. Whether you're replacing an existing breaker or completing a panel installation, confirming compatibility with your load center is always recommended before installation.

Key Features and Benefits

• 150 Amp current rating: 150 Amp current rating.
• Two-pole design: For 120/240VAC systems.
• Type QNR residential main circuit breaker:
• Plug-in mounting: For compatible panels.
• Thermal magnetic trip: Helps protect against overloads and short circuits.
• 10kA interrupting capacity: At 120/240VAC.
• Reversed handle configuration:
• HACR rated: For heating and air conditioning equipment.
• Rated for 50/60Hz operation:
• Panel space requirement: Requires four panel spaces.


Technical Specifications

• Part Number: QN2150R

• Type: QNR

• Poles: 2

• Amperage: 150 Amps

• Voltage Rating: 120/240VAC

• Interrupting Capacity: 10kA @ 120/240VAC

• Trip Type: Thermal Magnetic

• Mounting Style: Plug-In

• Handle: Reversed

• Frequency: 50/60Hz

• HACR Rated: Yes

• Ambient Temperature: 40°C

• Panel Spaces Required: 4

• Dimensions:
  • Height: 6.44 in.
  • Width: 2.00 in.
  • Depth: 2.38 in.

Material Compliance and Certifications

• HACR rated:
• Thermal magnetic protection:
• Rated for 120/240VAC, 50/60Hz operation:
• Designed for use in ambient temperatures up to 40°C:


Where It Works Best

• The QN2150R is commonly used as a residential main circuit breaker in compatible load centers requiring a 150 Amp, 2-pole, Type QNR breaker. It's also a good fit for residential electrical service upgrades, replacement main breakers, and HVAC-related installations that require HACR-rated overcurrent protection.
