QMQB7036R w/ Mounting Kit - 600Amp Panelboard Switch

QMQB7036R w/ Mounting Kit - 600Amp Panelboard Switch

The Federal Pacific QMQB7036R is a 3-pole, 600 amperes, 600 volts AC, fusible, single-unit, bolt-in type panel switch designed for robust performance in industrial and commercial electrical distribution systems. This high-capacity switch is engineered to accommodate Class RK1 and RK5 fuses, providing superior flexibility and protection for critical circuits.

Key Features and Benefits

• Fusible Switch Style: Accepts Class RK1 and RK5 fuses, offering broad compatibility with different fuse types for optimal protection.
• Bolt-In Mounting: Includes a mounting kit for easy and secure installation in QMQB and FDP style panelboards and switchgear systems.
• Versatile Use: Bolt-in type mounting system allows for easy installation in QMQB and FDP style panelboards and switchgear systems.
• Indoor Use: NEMA 1 rating ensures the switch is ideal for indoor environments where protection from dust and non-corrosive elements is sufficient.


Technical Specifications

• Voltage Rating: 600V AC

• Amperage Rating: 600A

• Poles: 3

• Phase: 3

• Fuse Class: RK1, RK5

• NEMA Rating: 1 (Indoor use)

• Configuration: Single (Single switch setup)

• Mounting Type: Bolt-in type (includes mounting kit)
• Dimensions: 22.25"W x 13.75"H x 6.25"D

• Weight: 23.25 lbs


Material Compliance and Certifications

• UL Listed: Meets all industry safety standards and regulatory requirements for electrical systems. Certified to ensure optimal performance in demanding environments.


Suitability

• The QMQB7036R is ideally suited for commercial and industrial environments, especially where safe and reliable power distribution is critical. It is perfect for use in electrical panels, switchboards, and switchgear systems, particularly those requiring robust overcurrent protection. The NEMA 1 rating makes it best suited for indoor environments without the need for additional external protection from environmental hazards.
