QDL22225 - 225 Amp Circuit Breaker

QDL22225 - 225 Amp Circuit Breaker

Choose the QDL22225 Circuit Breaker from Schneider Electric’s PowerPact™ Q-frame series to protect your electrical system with confidence. This 2-pole breaker carries a 225-amp rating and runs at 240 volts AC, making it a strong choice for residential, commercial, and light industrial applications. With its 25kA interrupting capacity, it responds quickly to overloads and short circuits, preventing damage to your wiring and equipment.

Key Features and Benefits

• Delivers Reliable Protection: Handles up to 240 volts AC with a 25kA breaking capacity to safeguard circuits under heavy loads.
• Trips Accurately: Uses thermal-magnetic trip technology to react instantly to electrical faults.
• Reduces Environmental Impact: Belongs to Schneider’s Green Premium™ line, meeting RoHS and REACh standards and using sustainable materials.
• Withstands Long-Term Use: Performs for 5,000 mechanical cycles, lowering replacement and maintenance needs.
• Fits Multiple Installations: Supports lug and bus-mounted setups, allowing easy integration into different panels.


Technical Specifications

• Current Rating: 225A

• Poles: 2

• Interrupting Capacity: 25kA at 240VAC

• Voltage: 240V AC, 50/60 Hz

• Impulse Withstand Voltage: 8kV

• Continuous Current: 80%

• Magnetic Trip: 2400A

• Magnetic Hold: 1200A

• Dimensions:
  • Height: 6.47 inches
  • Width: 3.00 inches
  • Depth: 3.93 inches
• Certifications: UL Listed, CSA Certified, IEC Compliant


Certifications and Environmental Standards

• Meets RoHS/REACh Standards: Complies with strict global safety and environmental regulations.
• Earns Green Premium™ Certification: Contains no mercury, PVC, or halogens, making it safe for sustainable building projects.
• Carries UL and CSA Approval: Ensures proven safety and performance in electrical systems.


Suitability

• Install this breaker in homes, commercial buildings, or industrial facilities where you need dependable overcurrent protection. Mount it in enclosures, metering equipment, panelboards, or switchboards, and rely on it to keep your system running safely and efficiently. With its long-lasting build and eco-friendly design, the QDL22225 gives you strong protection you can trust.
