QDL22200 - 200 Amp Circuit Breaker

QDL22200 - 200 Amp Circuit Breaker

Choose the QDL22200 200 Amp Circuit Breaker from Schneider Electric’s PowerPact™ Q-Frame series to protect your electrical distribution system with confidence. This 2-pole breaker delivers 25kA breaking capacity at 240VAC, effectively preventing damage from overloads and short circuits. Its compact size (6.47” x 3.00” x 3.93”) fits tight spaces, while the unit-mount design with lugs on both ends allows you to install it quickly in panelboards, switchboards, or standalone enclosures.

Key Features and Benefits

• Interrupts High Fault Currents: With a 25kA rating at 240VAC, this breaker stops dangerous electrical surges fast, protecting your equipment and system.
• Provides Dual Protection: The thermal-magnetic trip unit responds instantly to short circuits and sustained overloads, keeping your operation safe.
• Fits Tight Spaces: The slim footprint makes installation easy in compact electrical panels without reducing power capacity.
• Supports Green Compliance: Schneider Electric designs this breaker to meet RoHS and REACh standards, eliminating harmful substances for safer installations.
• Withstands Harsh Conditions: The breaker endures up to 5,000 no-load cycles and operates reliably between -40°C and 70°C, ensuring long-term performance.

Technical Specifications

• Rated Current (In): 200A
• Poles: 2
• Breaking Capacity: 25kA at 240VAC
• Rated Voltage (Ue): 240VAC, 50/60 Hz
• Magnetic Tripping Current: 2400A
• Continuous Current Rating: 80%
• Dimensions:
  • Height: 6.47 inches
  • Width: 3.00 inches
  • Depth: 3.93 inches
• Mounting Style: Unit mount with lugs
• Certifications: UL Listed, CSA, IEC

Material Compliance and Certifications

• Industry Standards: Schneider Electric manufactures the QDL22200 breaker to meet UL, CSA, and IEC safety standards.
• Green Certification: The Green Premium™ certification highlights its sustainable design, while RoHS and REACh compliance confirms it contains no restricted substances.

Suitability

• You can install this circuit breaker in commercial and industrial electrical systems to safeguard power distribution. It fits seamlessly into panelboards, switchboards, or standalone enclosures, making it ideal for both new installations and system upgrades. Electrical professionals trust the QDL22200 for dependable, easy-to-integrate circuit protection.
