QDF32200TS - 200 Amp Circuit Breaker

QDF32200TS - 200 Amp Circuit Breaker

The QDF32200TS is a 3-pole, 200-amp thermal magnetic circuit breaker designed to provide dependable overcurrent and short-circuit protection for commercial and industrial electrical distribution systems. Featuring a 25kA interrupting capacity at 240VAC, this breaker is built to help safeguard electrical equipment and minimize the risk of damage caused by overloads and fault conditions. Its non-interchangeable trip unit ensures consistent trip characteristics throughout the breaker's life, making it a reliable choice for applications requiring fixed protection settings. The breaker is equipped with 1/4-20-inch studs on both the line and load sides, allowing for secure cable terminations in demanding installations. Whether you're maintaining existing equipment, replacing a failed breaker, or supporting a new electrical project, the QDF32200TS offers dependable performance and long-term value for a wide range of power distribution applications.

Key Features and Benefits

• 200 Amp current rating for higher-capacity electrical distribution systems.
• 3-pole configuration designed for three-phase power applications.
• Thermal magnetic trip mechanism provides protection against both overloads and short-circuit faults.
• 25 kA interrupting capacity at 240 VAC helps safely interrupt high fault currents.
• Non-interchangeable trip unit delivers fixed, dependable circuit protection.
• 1/4-20-inch line- and load-side studs provide secure, reliable electrical connections.
• Designed for long-lasting performance in commercial and industrial environments.
• Ideal for maintenance, replacement, and equipment upgrades that require compatible QDF breakers.


Technical Specifications

• Part Number: QDF32200TS

• Type: QDF

• Trip Unit: Thermal Magnetic, Non-Interchangeable

• Poles: 3

• Current Rating: 200 Amps

• Interrupting Capacity: 25kA @ 240VAC

• Voltage Rating: 240VAC

• Dimensions:
  • Height: 6.5 in.
  • Width: 4.5 in.
  • Depth: 3.13 in.
• Line Connection: 1/4-20 in. Studs

• Load Connection: 1/4-20 in. Studs


Material Compliance and Certifications

• Manufactured for use in compatible electrical distribution systems. Thermal magnetic protection helps meet common electrical protection requirements for overload and short-circuit conditions.
• Designed to be installed by qualified electrical professionals and used in accordance with applicable electrical codes and manufacturer specifications. Refer to the product markings and accompanying documentation for specific certifications, approvals, and compliance information applicable to the individual unit.


Where It Works Best

• The QDF32200TS is well-suited for commercial buildings, industrial facilities, manufacturing operations, electrical distribution panels, switchboards, and other three-phase power systems requiring a 200-amp, 3-pole thermal-magnetic circuit breaker. It is an excellent choice for protecting feeders and branch circuits serving large equipment, motors, machinery, and other critical electrical loads where dependable overcurrent protection and secure stud-type connections are essential. Its fixed trip design makes it especially appropriate for applications that require consistent protection settings without adjustable trip components.
