QBHW1070 - 70Amp Circuit Breaker
QBHW1070 - 70Amp Circuit Breaker
Couldn't load pickup availability
QBHW1070 - 70Amp Circuit Breaker
The Eaton QBHW1070 is a robust and reliable solution for safeguarding electrical circuits in industrial and commercial applications. As part of Eaton's renowned Quicklag series, this thermal magnetic circuit breaker offers unmatched protection and performance, ensuring the continuity of your operations. With a 70-amp rating and a high interrupt capacity of 22 kAIC, it is designed to handle demanding environments where electrical reliability is crucial.
Key Features and Benefits:
- Superior Protection: The QBHW1070 features a thermal-magnetic trip mechanism that provides both instantaneous and long-term protection against overcurrents and short circuits. This dual functionality ensures your circuits are shielded from damage caused by electrical faults.
- High Interrupt Capacity: With a 22,000 AIC rating, this breaker can interrupt high fault currents, making it suitable for applications with significant power demands.
- Compact Design: Measuring only 3.75 inches in length, 1 inch in width, and 3.5 inches in height, this breaker offers a space-efficient solution without compromising on performance. Its lightweight design (0.33 lb) simplifies installation and handling.
- Versatile Voltage Rating: Rated for both 120V and 240V applications, the QBHW1070 can be deployed in a variety of electrical systems, enhancing its versatility across different setups.
- Non-Interchangeable: Ensures integrity and safety, as the breaker cannot be easily tampered with or replaced with incompatible units, maintaining system reliability.
Technical Specifications:
- Amperage Rating: 70 Amps
- Interrupt Capacity: 22 kAIC
- Voltage Rating: 120/240 Volts
- Trip Type: Thermal-Magnetic
- Number of Poles: 2
- Dimensions: Length: 3.75 in, Width: 1 in, Height: 3.5 in
- Weight: 0.33 lbs
Material Compliance and Certifications:
- UL Listed: Ensures the QBHW1070 meets rigorous safety standards set by Underwriters Laboratories.
- CSA Certified: Complies with the Canadian Standards Association requirements, guaranteeing performance and safety in Canadian applications.
- HACR Rated: Suitable for Heating, Air Conditioning, and Refrigeration applications, providing robust performance under varied thermal conditions.
Suitability:
- The Eaton QBHW1070 is ideal for protecting industrial and commercial circuits where reliability and safety are paramount. Its design caters to heavy-duty applications, including manufacturing plants, commercial buildings, and HVAC systems. Whether you are upgrading your electrical infrastructure or installing new systems, the QBHW1070 provides the dependable performance you need to keep your operations running smoothly.
