QBGF1020 - 20 Amp Circuit Breaker

QBGF1020 - 20 Amp Circuit Breaker

The QBGF1020 is a 20-amp, single-pole, bolt-on thermal-magnetic circuit breaker designed for use in your compatible electrical distribution equipment. This breaker protects against common electrical issues, such as overloads and short circuits, by combining thermal and magnetic trip functions in a single compact unit. With a 10,000-ampere interrupting capacity at 120VAC, the QBGF1020 is built to handle fault conditions within its rated specifications. Its bolt-on mounting style allows for a secure connection in approved applications, making it a suitable choice for your commercial, industrial, and maintenance-related electrical projects that require dependable circuit protection.

Key Features and Benefits

• 20 Amp rating protects circuits requiring a 20 Amp breaker.
• Single-pole configuration designed for applications requiring a single protected circuit.
• The thermal-magnetic trip mechanism uses thermal protection for overload conditions and magnetic protection for short-circuit conditions.
• 10 kA.I.C. at 120 VAC, rated to interrupt fault currents up to 10,000 amps at 120 volts AC.
• Bolt-on mounting enables secure installation in compatible electrical equipment.
• The 1-inch width helps support efficient use of available panel space.

Technical Specifications

• Part Number: QBGF1020

• Type: QBGF

• Circuit Breaker Style: Thermal Magnetic

• Mounting Type: Bolt-On

• Poles: 1

• Current Rating: 20 Amps

• Voltage Rating: 120VAC

• A.I.C. Rating: 10k

• Dimensions:
  • Height: 3.19 inches
  • Width: 1.00 inches
  • Depth: 2.50 inches

Material Compliance and Certifications

• The QBGF1020 is manufactured for use in electrical systems where circuit protection and proper equipment compatibility are important. The breaker should be installed in accordance with applicable electrical codes and used only with equipment approved for this breaker type and rating. Proper installation helps ensure safe operation and long-term performance.

Where It Works Best

• The QBGF1020 works best with compatible bolt-on electrical panels, distribution equipment, and other applications requiring a 20-amp thermal-magnetic circuit breaker. It is commonly suited for facility maintenance, commercial electrical systems, and replacement applications where matching the correct breaker type and specifications is essential. Its compact size, straightforward installation, and proven protection design make it a practical component for keeping electrical circuits operating safely.
