QBF32150TS - 150 Amp Circuit Breaker

QBF32150TS - 150 Amp Circuit Breaker

Protect your electrical installation with confidence using the QBF32150TS 150 A molded-case circuit breaker. Designed for three-phase systems at 240 VAC, this unit delivers dependable overcurrent protection and switching control. With its three-pole configuration and 150 A rating, it’s ideal for industrial and commercial panels where safety and performance can’t be compromised. The busbar-style connection (with studs on both line and load sides) makes wiring and maintenance quicker and more secure, reducing installation time and potential wiring faults.

Key Features and Benefits

• High Load Capacity & Safety: Built for 150 amps, this breaker handles heavy electrical loads with ease while offering reliable protection via a thermal-magnetic trip mechanism.
• Strong Fault Handling: It can interrupt fault currents up to 10 kA at both 120/208 V and 240 V, helping to limit damage during short-circuit events.
• Durable & Testable: Rated for up to 1,000 cycles under load (5,000 cycles no-load), it withstands daily operations. A built-in push-to-trip button allows easy manual testing.
• Compact & Practical: With dimensions of 6.47″ × 4.5″ × 3.93″, it fits neatly in many breaker panel arrangements without requiring excessive space.
• Easy to Connect: The busbar-style stud connections simplify installation, and reduce the risk of loose terminations or miswiring.

Technical Specifications

• Operational Voltage: 240 V AC, 50/60 Hz
• Poles: 3
• Continuous Current Rating: 80 % (of 150 A)
• Interrupting Rating: 10 kA at 120/208 V & 240 V
• Magnetic Hold / Trip Currents: Hold: 1,200 A, Trip: 2,400 A
• Mounting Mode: Unit-mount, busbar (studs both ends)
• Mechanical Durability: 1,000 cycles under load; 5,000 cycles no load
• Dimensions (H × W × D): 6.47″ × 4.5″ × 3.93″ (164.34 mm × 114.30 mm × 99.82 mm)

Material Compliance and Certifications

• Environmental Compliance: Fully RoHS (Restriction of Hazardous Substances) and REACh compliant, ensuring minimal hazardous substance use.
• Green Premium Design: Part of Schneider Electric’s eco-aware product line, crafted to reduce environmental impact over its lifecycle.
• Safety & Standards Certifications: UL Listed, CSA Certified, NOM-003-SCFI, and IEC certified, demonstrating global compliance to electrical safety and performance norms.

Where It Works Best

• This circuit breaker is perfect for systems where dependable overcurrent protection is essential — especially in commercial and industrial settings. Use it in distribution or control panels for machinery, HVAC systems, or power distribution networks. Because of its solid interrupt capability and three-phase design, it’s well suited for critical loads that must stay safe during faults or overloads. Wherever you need to balance compact form with high reliability, this breaker performs confidently.
