Q2100HH - 100Amp Circuit Breaker

Q2100HH - 100Amp Circuit Breaker

When you're replacing a circuit breaker, getting the details right matters. The Q2100HH is a 100-amp, 2-pole HQP plug-in circuit breaker rated for 120/240VAC, with a 65kA I.A.C. rating. It's a compact breaker, just 3.13 inches high, 2 inches wide, and 2.56 inches deep, but it offers the electrical ratings needed for compatible applications requiring 100A, two-pole circuit protection. The Q2100HH is also HACR-rated, allowing it to be used in applicable heating, air-conditioning, and refrigeration applications. Its plug-in design keeps things straightforward for qualified electricians working with compatible equipment. If you're replacing an existing Q2100HH, or you've been given this part number for a project, the specifications below make it easy to double-check the important details before installation.

Key Features and Benefits

• 100-amp, 2-pole configuration for applications requiring these specific electrical ratings.
• Rated 65 kA.I.C. at 120/240VAC, providing a high interrupting capacity for compatible systems.
• Plug-in design for use with electrical equipment designed to accept this breaker type.
• HACR rated for applicable heating, air-conditioning, and refrigeration circuits.
• 40°C, rated per the available product specifications.
• Compact 3.13" H x 2.00" W x 2.56" D dimensions.
• HQP breaker type for straightforward identification when matching an existing breaker or equipment requirement.

Technical Specifications

• Part Number: Q2100HH

• Type: HQP

• Amperage: 100 Amps

• Poles: 2

• Voltage: 120/240VAC

• A.I.C. Rating: 65k @ 120/240VAC

• Mounting Style: Plug-In

• HACR Rated: Yes

• Temperature Rating: 40°C

• Height: 3.13 in.

• Width: 2.00 in.

• Depth: 2.56 in.


Material Compliance and Certifications

• The available specifications list the Q2100HH as HACR-rated and provide a 40°C temperature rating. No other material-compliance or certification information has been provided for this product. If your project has specific certification or compliance requirements, check the applicable product documentation before installation rather than relying on appearance or part number alone.

Where It Works Best

• The Q2100HH makes sense when the job calls for a 100A, 2-pole HQP plug-in breaker rated for 120/240VAC with a 65k A.I.C. rating. It may be used in compatible electrical distribution equipment as well as qualifying HVAC and refrigeration applications where an HACR-rated breaker with these specifications is required.
