PDG23M0100TFFL - 100Amp Circuit Breaker

PDG23M0100TFFL åÊ- 100Amp Circuit Breaker

The Eaton PDG23M0100TFFL Power Defense Molded Case Circuit Breaker delivers exceptional electrical protection and performance for industrial and commercial power systems. This globally rated Frame 2 circuit breaker is designed for demanding applications, featuring a 100A rating, a breaking capacity of 65 kA at 480V, and a robust three-pole configuration. Its fixed thermal-magnetic trip unit ensures precise and consistent protection against overloads and short circuits, making it a reliable and efficient choice for modern power distribution networks.

Key Features and Benefits

• High Interrupt Capacity: Offers 65 kAIC at 480V (UL) and up to 100 kAIC at 240V (IEC), providing robust fault protection in critical systems.
• Reliable Protection: Fixed thermal-magnetic trip unit ensures consistent overload and short-circuit protection, minimizing risks to equipment and personnel.
• Ease of Installation: Features standard load-only terminals (PDG2X3T100) for simplified installation and reduced maintenance efforts.

Technical Specifications

• Frame Type: Frame 2, Power Defense Series
• Poles: 3-pole
• Amperage Rating: 100A
• Voltage Rating: 600 Vac max
• Interrupt Ratings: 65 kAIC at 480V;åÊ100 kAIC at 240V;åÊ35 kAIC at 600V

• Weight: 1.82 kg
• Dimensions: 88.9 mm x 104.6 mm x 152.4 mm

Material Compliance and Certifications

• RoHS Compliant: Reflects Eaton's commitment to sustainable and eco-friendly product development.
• Global Certifications: Ensures adherence to stringent safety and performance standards for international usage.

Suitability

• The Eaton PDG23M0100TFFL Circuit Breaker is ideal for industrial facilities, data centers, and large commercial buildings requiring high fault tolerance and reliable electrical protection. Its advanced interrupt capacity and durable construction make it a trusted choice for safeguarding critical power distribution systems.

Choose the Eaton PDG23M0100TFFL Circuit Breaker for industry-leading safety, efficiency, and reliability, ensuring seamless performance in any application.
