PDG23M0090TFFL - 90 Amp Circuit Breaker

PDG23M0090TFFL - 90 Amp Circuit Breaker

When you need a 90A breaker for a compatible three-phase application, the Eaton PDG23M0090TFFL gives you a straightforward combination of circuit protection, compact size, and high interrupting capacity. This Power Defense molded-case circuit breaker is a Frame 2, 3-pole unit rated at 90 amps, with an interrupting rating of 65 kA at 480 VAC. It uses a fixed-trip design and comes with load lugs, so there are no unnecessary adjustments when the application calls for these specifications. Size can matter when you're working inside electrical equipment, too. At approximately 4.19 inches high, 6 inches wide, and 3.5 inches deep, this breaker provides substantial fault-current interrupting capability in a relatively compact package. If you're replacing an existing PDG23M0090TFFL or matching a breaker to specific system requirements, the important details are easy to identify: 90A, three-pole, fixed-trip, load lugs, and 65kA at 480 VAC.

Key Features and Benefits

• 90-amp rating for applications requiring 90A circuit protection.
• Three-pole configuration for compatible three-phase electrical systems.
• A 65 kA interrupting rating at 480 VAC provides substantial fault-current interrupting capacity.
• Fixed trip design keeps the protection configuration simple and consistent.
• Load lugs included for use with compatible electrical equipment.
• Frame 2 construction provides a relatively compact footprint.
• Part of the Eaton Power Defense molded case circuit breaker family.

Technical Specifications

• Manufacturer: Eaton

• Part Number: PDG23M0090TFFL

• Product Family: Power Defense

• Breaker Type: Molded Case Circuit Breaker (MCCB)

• Frame: Frame 2

• Poles: 3

• Amperage: 90A

• A.I.C. Rating: 65kA at 480 VAC

• Trip: Fixed

• Lugs: Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• The PDG23M0090TFFL is part of Eaton's globally rated Power Defense molded case circuit breaker line. Certification and material compliance requirements can vary depending on the specific breaker and its intended application. When a particular UL, CSA, IEC, RoHS, or other compliance requirement is important to a project, confirm the markings on the breaker and the manufacturer's documentation for this exact part number before installation.

Where It Works Best

• The Eaton PDG23M0090TFFL is a good fit for commercial and industrial electrical applications that require a 90A, 3-pole molded-case circuit breaker with a 65kA rating at 480 VAC. Depending on the system and equipment requirements, that can include electrical distribution equipment, commercial facilities, manufacturing environments, machinery, and other compatible three-phase installations.

• It's also a practical choice when replacing an existing breaker with the same part number and electrical characteristics. Before making a replacement, consider more than just amperage. Confirm the PDG23M0090TFFL part number, three-pole configuration, voltage, interrupting rating, physical dimensions, trip type, lug arrangement, and compatibility with the equipment. Those details matter when you're trying to get the right breaker into the right application.
