PDG23M0090TFFJ - 90Amp Circuit Breaker

PDG23M0090TFFJ - 90Amp Circuit Breaker

The Eaton PDG23M0090TFFJ Power Defense Molded Case Circuit Breaker offers powerful and reliable protection for three-phase electrical systems. With a 90Amp rating and a robust interrupting capacity of 65kAIC at 480V, this globally certified breaker is designed to safeguard industrial, commercial, and institutional power setups. Its advanced thermomagnetic trip technology ensures precise fault detection and rapid response, reducing the risk of system downtime and damage.

Key Features and Benefits:

• High Fault Interruption Capacity: Rated at 65kAIC at 480V, providing dependable fault protection for critical systems.
• Advanced Trip Technology: Thermomagnetic trip (T-M, Fxd-Fxd) ensures accurate fault detection and rapid interruption for improved system safety.
• Three-Pole Configuration: Designed for versatile use in three-phase systems, offering reliable protection across multiple circuits.

Technical Specifications:

• Amperage Rating: 90Amp
• Voltage Rating: 600V maximum
• Frame Type: PD2 Global, Frame 2
• Interrupting Ratings: 65kAIC at 480V (UL), 100kAIC at 240V (UL), 35kAIC at 600V (UL/CSA), 70kAIC Icu at 380-415V (IEC), 50kAIC Icu at 440V (IEC), 22kAIC Icu at 250 Vdc, 10kAIC Icu at 690V (IEC)
• Dimensions: 88.9 mm (depth) x 152.4 mm (height) x 104.6 mm (width)
• Weight: 1.82 kg

Material Compliance and Certifications:

• Built to meet rigorous safety and environmental standards, the PDG23M0090TFFJ carries certifications from UL, IEC, CSA, and CCC. Its RoHS compliance ensures minimal environmental impact, aligning with sustainable development goals.

Suitability:

• This breaker is ideal for three-phase electrical systems in industrial facilities, commercial buildings, and institutional environments. Its high interrupting capacity and compact design make it an excellent choice for modern power distribution systems requiring reliable performance and adherence to global standards.
