PDG23M0080TFFJ - 80 Amp Circuit Breaker

PDG23M0080TFFJ - 80 Amp Circuit Breaker

The Eaton PDG23M0080TFFJ is a 3-pole, 80-amp molded-case circuit breaker from the Global Rated Power Defense line. Built on a Frame 2 platform, it has an interrupting rating of 65 kA at 480 VAC and comes with a fixed trip, as well as line and load lugs. It's a practical option for commercial and industrial electrical systems that require this specific combination of amperage, pole configuration, and fault-current protection. With dimensions of 4.19" high × 6.0" wide × 3.5" deep, the breaker also has a relatively compact footprint. If you're replacing an existing breaker, the PDG23M0080TFFJ part number is a useful starting point—but it's still important to compare the full electrical and physical specifications before installation.

Key Features and Benefits

• 80A rating for applications requiring an 80-amp breaker
• Three-pole configuration for compatible three-pole electrical systems
• 65kA interrupting rating at 480 VAC for applications with higher available fault-current requirements
• Frame 2 Power Defense design
• Fixed trip for a straightforward protection configuration
• Line and load lugs included for secure electrical connections
• Compact dimensions of 4.19" H × 6.0" W × 3.5" D
• Clearly identified ratings make it easier to compare against an existing breaker or equipment specification

Technical Specifications

• Part Number: PDG23M0080TFFJ

• Manufacturer: Eaton

• Product Family: Global Rated Power Defense

• Type: Molded Case Circuit Breaker

• Frame: Frame 2

• Poles: 3

• Amperage: 80A

• A.I.C. Rating: 65kA @ 480 VAC

• Trip: Fixed

• Connections: Line & Load Lugs

• Height: 4.19 in.

• Width: 6.0 in.

• Depth: 3.5 in.


Material Compliance and Certifications

• Certification and material-compliance requirements can vary by application and product configuration. If your project requires specific approvals or compliance documentation, verify that the PDG23M0080TFFJ complies with the current manufacturer documentation before installation. This is especially important when the breaker will be used in equipment or facilities subject to specific electrical, regulatory, or project requirements.

Where It Works Best

• The PDG23M0080TFFJ is intended for compatible commercial and industrial electrical applications requiring a 3-pole, 80A molded-case circuit breaker with a 65kA rating at 480 VAC. Depending on the equipment requirements, it can be a fit for electrical distribution systems, industrial equipment, commercial facilities, machinery, and breaker replacement projects.
