PDG23M0070TFFJ - 70Amp Circuit Breaker

PDG23M0070TFFJ - 70Amp Circuit Breaker

The Eaton PDG23M0070TFFJ Power Defense Molded Case Circuit Breaker is a highly reliable and versatile three-pole solution engineered for superior circuit protection in industrial, commercial, and institutional applications. Rated at 70Amp with an exceptional interrupting capacity of 65kA at 480V, this breaker combines advanced safety features with a globally compliant design, making it an ideal choice for demanding power systems.

Key Features and Benefits:

• High Fault Protection: Capable of interrupting 65kA at 480V (UL), ensuring robust safety for critical electrical systems.
• Three-Pole Configuration: Offers comprehensive protection for three-phase systems, supporting efficient and reliable power distribution.
• Thermomagnetic Trip Unit: Features a fixed-fixed (Fixed-Fixed) trip mechanism for precise fault detection and quick response to overcurrent scenarios.
• Standard Terminals: Line and load terminals simplify installation, providing seamless compatibility with various system configurations.

Technical Specifications:

• Amperage Rating: 70Amp
• Voltage Rating: 600V maximum
• Interrupting Ratings: 65kA at 480V (UL), 100kA at 240V (UL), 35kA at 600V (UL/CSA), Multiple global ratings, including 70kA at 380-415V (IEC) and 50kA at 440V (IEC)
• Dimensions: 88.9 mm (depth) x 152.4 mm (height) x 104.6 mm (width)
• Weight: 1.82 kg

Material Compliance and Certifications:

• Certifications: Adheres to rigorous international safety standards, including UL 489 and IEC 60947-2 certifications, ensuring optimal performance and reliability.
• RoHS Compliance: Demonstrates Eaton‰۪s commitment to sustainability and environmentally responsible manufacturing.

Suitability:

• Ideal for three-phase systems in industrial facilities, commercial properties, and critical infrastructure, this breaker ensures dependable protection in environments with high power demands and fault risks.
